Specifications

Imaging Sensor
LCD Screen Type
Pixels
Horizontal View Angle
Working length
Camera head diameter
Shaft diameter
Focus length
Auto Power OFF (APO)
Waterproof Capacity
Power Supply
Consumption Current (Max.)
Dimensions
Weight
Operating Temperature
Operating Humidity (Display)
actoolsupply.com
CMOS
2.36" TFT-LCD
480 x 234
50 degrees
1m (39")
17mm (0.67")
9mm (0.35")
5.1 cm (2")
OFF /5 min. /10 min. selectable
IP67 (imager head and tube)
4 x 'AA' 1.5V batteries
150mA
211 x 83 x 76mm (8.3 x 3.3 x 3") meter body only
0.61 kg (1.35 lbs) (meter & tube)
-10°C~+50°C (+14°F~+122°F)
15~85%RH
5
