Specifications

Camera Specifications
Camera image resolution
Frame rate
Probe head and body
diameter
Probe length and diameter
Probe head material
Reel frame diameter
Reel material
Worklights
Field of View (FOV)
Depth of Field (DOF)
Accessories
Operating and storage
temperature
Water-proof, ingress rating
Liquids approved for probe
submersion
Weight
#NAS100128; r. AC/88003/88004; en-US
640 x 480 pixels
30 frames per second (fps)
1.1 in. (28 mm)
98.4 ft. (30 m) length; 0.2 in. (6 mm) diameter
Stainless steel
11.8 in. (300 mm)
Steel frame; HDPE cable reel
Eight (8) front facing LED lamps
150°
0.4 to 4.0 in. (10 to 100 mm)
Probe brush attachment (included)
14℉ to 140℉ (–10℃ to 60℃)
Probe tip and body: IP 67 (IEC 60529);
Protected from submersion in water up to
32.8 ft. (10 m) for 30 minutes, maximum
Brake and transmission fluid, diesel fuel, un-
leaded gasoline, engine oil, and CPC hy-
draulic fluid (46AWS)
7.7 lbs. (3.5 kg)
