Everlast POWERARC 300ST Operator's Manual
  1. Manuals
  2. Brands
  3. Everlast Manuals
  4. Welding System
  5. POWERARC 300ST
  6. Operator's manual

Everlast POWERARC 300ST Operator's Manual

Analog dc stick/dc tig igbt inverter welder
Hide thumbs
Table of Contents

Advertisement

Quick Links

EVERLAST
POWERARC 300ST
Analog DC Stick/DC TIG IGBT Inverter Welder
CC
SMAW
GTAW
IGBT
1&3
PHASE
DC
Operator's Manual for the PowerARC 300ST
Safety, Setup and General Use Guide
Rev. 3
1 001229-16
everlastwelders.com
Specifications and accessories subject to change without notice.
1-877-755-9353
329 Littlefield Ave. South San Francisco, CA 94080 USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERARC 300ST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Everlast POWERARC 300ST

Summary of Contents for Everlast POWERARC 300ST

  • Page 1 POWERARC 300ST Analog DC Stick/DC TIG IGBT Inverter Welder SMAW GTAW IGBT 1&3 PHASE Operator’s Manual for the PowerARC 300ST Safety, Setup and General Use Guide Rev. 3 1 001229-16 everlastwelders.com Specifications and accessories subject to change without notice. 1-877-755-9353...

  • Page 2: Table Of Contents

    The owner of this product assumes all liability for its use and maintenance. Everlast Power Equipment INC. does not warrant this product or this document for fitness for any particular purpose, for per- formance/accuracy or for suitability of application.

  • Page 3: Letter To The Customer

    Your unit registration is important should any information such as product updates or re- calls be issued. It is also important so that we may track your satisfaction with Everlast products and services. If you are unable to register by website, contact Everlast directly through the sales department through the main customer service number in your country.

  • Page 4: Everlast Contact Information

    Serial number: __________________________ Model number: ____________________________ Date of Purchase___________________________ Contact Information Everlast US: Everlast consumer satisfaction email: sales@everlastwelders.com Everlast Website: everlastwelders.com Everlast Technical Support: support@everlastwelders.com Everlast Support Forum: http://www.everlastgenerators.com/forums/index.php Main toll free number: 1-877-755 WELD (9353) 9am—5pm PST M-F 11am-4pm PST Sat.

  • Page 5: Safety Precautions

    Safe operation and proper maintenance is your responsibility. We have compiled this operator’s manual, to instruct you in basic safety, oper- ation and maintenance of your Everlast product to give you the best possible experience. Much of welding and cutting is based upon experience and com- mon sense.
  • Page 6 SAFETY PRECAUTIONS These safety precautions are for protection of safety and health. Failure to follow these guidelines may result in serious injury or death. Be careful to read and follow all cautions and warnings. Protect yourself and others. Welding and cutting processes produce high levels of ultraviolet (UV) radiation that can cause severe skin burn and damage.
  • Page 7 SAFETY PRECAUTIONS WARNING! Persons with pacemakers should not weld, cut or be in the welding area until they consult with their physician. Some pacemakers are sensitive to EMF radiation and could severely malfunction while welding or while being in the vicinity of someone welding.
  • Page 8 SAFETY PRECAUTIONS continued WARNING! Electrical shock can kill. Make sure all electrical equipment is properly grounded. Do not use frayed, cut or otherwise damaged cables and leads. Do not stand, lean or rest on ground clamp. Do not stand in water or damp areas while weld- ing or cutting.

  • Page 9: Section 1: Specifications

    PERFORMANCE AND FEATURE COMPARISON IMPORTANT: The PowerARC 300 is DC output only and is not designed to weld aluminum or magnesium. Specification: PowerARC 300ST Stick/TIG welder INVERTER TYPE ANALOG CONTROLLED IGBT INPUT VOLTAGE ±10%;PHASE/FREQUENCY 220V; 1 Phase and 3 Phase /50-60Hz MAXIMUM INPUT AMPS (I₁max)

  • Page 10: Section 2: General Setup And Operation

    The intensity of the hot start contains with the PowerARC 300ST or other inverter welders. more adjustability than is typically required to make In order to control the maximum input amps, the good starts.
  • Page 11 Package: overcurrent light is lit, turn the machine off and check The PowerARC 300ST includes a stick electrode holder for wiring faults, then turn the unit back on to see if with cable, and a work clamp with cable. Cables are the light has cleared.

  • Page 12: Front Panel

    Section 2 GENERAL SETUP AND OPERATION PowerARC 300ST Front Panel View ON INDICATOR DIGITAL AMP METER LIFT TIG/STICK SWITCH DUTY CYCLE INDICATOR AMP/CURRENT CONTROL OVER CURRENT INDICATOR ARC FORCE CONTROL HOT START CONTROL NEGATIVE (-) STANDARD CONNECTOR 6010 POSITIVE (+) CONNECTOR...

  • Page 13: Rear Panel

    Section 2 GENERAL SETUP AND OPERATION PowerARC 300ST Rear Panel View MAIN POWER SWITCH/BREAKER 1~220 V GROUND BOLT 3~220v POWER CORD Even though the unit is grounded by the main ground wire to the chassis, an additional bonded ground may be necessary in some locations to comply with code. Consult a locally licensed electrician concern-...

  • Page 14: Wiring

    STALLING THE WELDER. See page 20 for further details and explanation. IMPORTANT: EVERLAST IS NOT RESPONSIBLE FOR DAMAGE OR INJURY RESULTING FROM IMPROPERLY WIRED WELDERS! Even though the unit is grounded by the main ground wire to the chassis, an additional bonded ground may be necessary in some locations to Fe, Cu comply with code.

  • Page 15: Stick E6010 Configuration

    Section 2 GENERAL SETUP AND OPERATION PowerARC 300ST STICK E6010 WELDING CONFIGURATION 6010 WORK 6010(-) TORCH (+) NOTE: Also, suitable for use with E6011 and other electrodes with cellulose based flux such as E7010.

  • Page 16: Stick Configuration

    Section 2 GENERAL SETUP AND OPERATION PowerARC 300ST STANDARD WELDING CONFIGURATION 6010 WORK (-) NOTE: Use this configuration with most standard electrodes except ones with cellulose flux such as E6010/6011. TORCH (+) IMPORTANT: Most electrodes require DCEP (+). Always consult electrode manufacturer directions before using DCEN (-).

  • Page 17: Lift Tig Configuration

    The unit does not contain a gas solenoid valve to regulate pre-flow or post flow. A regula- tor is still needed to regulate max flow. To connect Everlast torches, some adaptation or modification of the torch gas line will be needed, as is the case with most gas valve torches to connect directly to the regulator.

  • Page 18: Stick Operation Technique/Information

    Section 2 GENERAL SETUP AND OPERATION STICK OPERATION TECHNIQUE STARTING METHODS Scratch/Match Method Tapping Method 1. Turn on the power switch on the rear of the unit. Allow unit to cycle through its start up program. Select stick on the selector switch. 2.

  • Page 19: Lift Start Technique

    Section 2 GENERAL SETUP AND OPERATION LIFT START TIG OPERATION Note: A Lift start should be done with a nearly seamless motion. Use a light touch and a quick motion for best results. <1/8” Position the edge of the ceramic cup on the metal. Do not touch the tungsten to the metal until ready. The tip is always live. Quickly rotate the cup so that the tungsten comes in brief contact (<...

  • Page 20: Trouble Shooting

    CAUSE/SOLUTION Machine will not turn on Check cords and wiring in the plug. Check circuit breaker. Contact Everlast Technical Support to check and replace main unit fuse. Machine runs, but will not weld and/or Check for sound work clamp connection. Make sure work/Torch cable is securely fastened to Red LED is on.

  • Page 21: Kit Contents

    Tong style Stick electrode holder, 10ft cable with DINSE 50 style connector Steel work clamp, 10ft cable with DINSE 50 style connector PowerARC 300ST DC Stick Inverter welder Manual NOTE: Kit contents, appearance, size and quantity are subject to change without notice.

  • Page 22: Notes

    Arc force = Dig = Inductance = Arc response Why doesn’t the PowerARC 300ST come with a power plug? The PowerARC 300ST is both a single phase and three phase machine. This means it can work in home shops and industrial factories with different power supplies. Single phase welders in North America use only three wires for 240V operation with two 120V lines arranged out of phase (measuring 240V between the hot legs and 120V to ground) with a third wire serving as a ground.
