5 How to Install
5
Figure 5.27: Position of ground terminals IP00, frame sizes
D
NOTE!
D2 and D4 shown as examples. D1 and D3 are equivalent.
5-36
Figure 5.28: Position of ground terminals IP21 (NEMA type
1) and IP54 (NEMA type 12)
®
MG.20.N5.22 - VLT
is a registered Danfoss trademark
®
VLT
AQUA Drive Design Guide
