Danfoss vlt aqua Design Manual page 143

®
VLT AQUA Drive Design Guide
525–690 V, frame sizes D, E and F
Bussmann
Size/Type E125085
JFHR2
P37K 170M3013
P45K 170M3014
P55K 170M3015
P75K 170M3015
P90K 170M3016
P110 170M3017
P132 170M3018
P160 170M4011
P200 170M4012
P250 170M4014
P315 170M5011
Table 5.14: Frame size D, 525–690 V
Size/Type Bussmann PN*
P355 170M4017
P400 170M4017
P500 170M6013
P560 170M6013
Table 5.15: Frame size E, 525–690 V
Size/Type Bussmann PN*
P630 170M7081
P710 170M7081
P800 170M7081
P900 170M7081
P1M0 170M7082
Table 5.16: Frame size F, Line fuses, 525–690 V
Size/Type
P630
P710
P800
P900
P1M0
Table 5.17: Frame size F, Inverter module DC Link Fuses, 525–690 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use.
Suitable for use on a circuit capable of delivering not more than 100,000 rms symmetrical amperes, 500/600/690 Volts maximum when protected by the
above fuses.
SIBA
Amps E180276
JFHR2
125 2061032.125
160 2061032.16
200 2061032.2
200 2061032.2
250 2061032.25
315 2061032.315
350 2061032.35
350 2061032.35
400 2061032.4
500 2061032.5
550 2062032.55
Rating
700 A, 700 V
700 A, 700 V
900 A, 700 V
900 A, 700 V
Rating
1600 A, 700 V
1600 A, 700 V
1600 A, 700 V
1600 A, 700 V
2000 A, 700 V
Bussmann PN* Rating
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
170M8611 1100 A, 1000 V
®
MG.20.N5.22 - VLT is a registered Danfoss trademark
Ferraz-Shawmut
E76491
JFHR2
6.6URD30D08A0125
6.6URD30D08A0160
6.6URD30D08A0200
6.6URD30D08A0200
6.6URD30D08A0250
6.6URD30D08A0315
6.6URD30D08A0350
6.6URD30D08A0350
6.6URD30D08A0400
6.6URD30D08A0500
6.6URD32D08A550
Ferraz
6.9URD31D08A0700
6.9URD31D08A0700
6.9URD33D08A0900
6.9URD33D08A0900
Siba
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.2000
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
20 781 32. 1000
5 How to Install
Internal
Option
Bussmann
170M3015
170M3015
170M3015
170M3015
170M3018
170M3018
170M3018
170M5011
170M5011
170M5011
170M5011
Siba
20 610 32.700
20 610 32.700
20 630 32.900
20 630 32.900
Internal Bussmann Option
170M7082
170M7082
170M7082
170M7082
170M7082
Siba
5
5-25
