• 10Base-T RJ-45 Ethernet port
• Raw Ethernet and two associated LED control signals available on 26-pin header
• Three CMOS-compatible serial ports: maximum asynchronous baud rate of 691,200 bps,
maximum synchronous baud rate of 5,529,600 bps. One port is configurable as a
clocked port.
• Six additional I/O lines are located on the programming port, can be used as I/O lines
when the programming port is not being used for programming or in-circuit debug-
ging—one synchronous serial port can also be used as two general CMOS inputs and
one general CMOS output, and there are two additional inputs and one additional out-
put.
Appendix A, "RabbitCore RCM2200 Specifications," provides detailed specifications for
the RCM2200.
In addition, three different RCM2200 models are available. A variant of the RCM2200,
the RCM2300, omits the Ethernet connectivity but offers a much smaller footprint, one-
half the size of the RCM2200.

1.2 Advantages of the RCM2200

• Fast time to market using a fully engineered, "ready to run" microprocessor core.
• Competitive pricing when compared with the alternative of purchasing and assembling
individual components.
• Easy C-language program development and debugging, including rapid production
loading of programs.
• Generous memory size allows large programs with tens of thousands of lines of code,
and substantial data storage.
• Integrated Ethernet port for network connectivity, royalty-free TCP/IP software.

1.3 Development and Evaluation Tools

A complete Development Kit, including a Prototyping Board and Dynamic C develop-
ment software, is available for the RCM2200. The Development Kit puts together the
essentials you need to design an embedded microprocessor-based system rapidly and effi-
ciently.
See the RabbitCore RCM2200 Getting Started Manual for complete information on the
Development Kit.
