With the RCM2200 plugged into the

MASTER

slots, it has full access to the RS-232 trans-

ceiver, and can act as the "master" relative to another RabbitCore RCM2200 or RCM2300

plugged into the

SLAVE

slots, which acts as the "slave."

This master/slave relationship is not used in the DeviceMate Development Kit where the

"target" RCM2300 is plugged into the

MASTER

slots, and the RCM2200, which is used

as the DeviceMate hardware platform, is plugged into the

slots. The special Dem-

SLAVE

onstration Board serves only as a means to connect the two RabbitCore modules together

to demonstrate the DeviceMate software features in Dynamic C.
