A
E. P
C
PPENDIX
ROGRAMMING
ABLE
Appendix E provides additional theoretical information for the Rabbit
™
2000
microprocessor when using the
and
connectors on
DIAG
PROG
the programming cable. The
connector is used only when the
PROG
programming cable is attached to the programming connector (header
J5) while a new application is being developed. Otherwise, the
DIAG
connector on the programming cable allows the programming cable to
be used as an RS-232 to CMOS level converter for serial communica-
tion, which is appropriate for monitoring or debugging a RabbitCore
system while it is running.
User's Manual
51
