Setting Parameters; Initial Print - FLASHFORGE 3D PRINTER Creator Pro Startup Manual

To heat the right extruder and feed material, click the right extruder on the upper right corner of the control panel and
manually modify the temperature in the "Right Target" setting for the extruder temperature control changing the
temperature to 220°C. A red line will be plotted in the temperature map. When the actual (Current) temperature
reaches 220°C you can pull the filament out.
6.5

Setting Parameters

Before generating Gcode, specific parameters can be set up to customize various aspects of the print. An explanation
to each of the settings can be found in the
7

Initial Print

CAUTION
Creator Pro has been leveled perfectly before leaving factory. However, it will get unleveled during long
distance
shipping, please do level the build plate again before starting a print. See below in instruction.
First, make sure that you've completed all the steps in the
1. Your dual extruder heads should be bolted in place,
2. Your filament guide tubes is connected,
3. Your filament is mounted on the spool holders.
Once all these have been completed, you can plug in your power supply. If everything is ready, then turn on the power
switch on the back of your Creator Pro.
Every printer will be leveled before shipped out, but we can't ensure that the platform won't move during delivery, so
it will be better to level platform before you begin to print. We will put one SD card within the 3D printer，there is a
file named PlateLeveling.x3g.Put the SD card into the slot,choose
PlateLeveling.x3gand click it, you will see the content
tighten four or five turns. I'm going to move the extruder to various positions for adjustment.In each position,
we will need to adjust 2 knobs at the same time. Nozzles are at the right height when you can just slide a sheet of
paper between the nozzle and the platform. Grab a sheet of paper to assist us. Please wait.You will find 3 knobs
under the platform,the extruder will move to different locations, in everylocation, you need to rotate2 knobs
toadjust.You can put one piece of paper between nozzle and platform,ifwhen you move the paper and can feel
thefriction(which means you can move the paper but it can't be scratched ), then level finished
During the process, what you should do is only click OK continuely, the screen will go to next page; and you also only
EXPLANATION OF GCODE
Un-boxing and Hardware Setup
below:Find the 3 knobs on the bottom of the platform and
SETTINGS.
section.
Print from SD ,click OK,then choose
１８
