5.4

Setting Tear-off position (optional, only for 5130P with tractors)

1) With the cover open, hold 【USER1】 + 【OFFLINE】 + 【USER2】 while powering on the printer. It beeps
once after implementing the paper detection action, while LED"DATA" blinks and other LEDs light up,
to indicate the activation of Calibrations mode.
2) Close the cover and press 【USER2】 , the printer beeps once and LED"DATA" is off, while other LEDs
light up.
3) Install the continuous paper in the tractors, and press 【USER1】 to load it. The printer will print as
below:
Adjust Tear-Off Position
【USER1】=-1, 【USER2】=+1, 【OFFLINE】=Exit & Save
Each step is 0.5mm
4) Press 【USER1】 or 【USER2】 to reduce or increase the tear-off position, respectively, by one step
of 0.5mm.
5) When satisfied with the setting, press 【OFFLINE】 to store it and reset the printer.
6) Switch off the printer to exit from Calibration menu.
44
