2) Close the cover, the printer resets. Press 【OFFLINE】, the printer beeps once. All LEDs light up.
3) Press 【USER1】, the printer beeps once. The TOF setting mode is activated. Load an A4 paper. A line
of twenty "—"s is printed and ejects the paper.
4) Now each press of 【USER1】 or 【USER2】 to reduce or increase the TOF , respectively, by one unit
of 1/60 inch.(Note: Beeps 3 times when reaches the limits.)
5) Repeat 3 to 4.
6) When satisfied with the TOF setting, press 【OFFLINE】 to permanently store the TOF . Automatically,
it switches to the Calibration menu.
7) Switch off the printer to exit from Calibration menu.
5.3

Setting Left margin

1) With the cover open, hold 【USER1】 + 【OFFLINE】 + 【USER2】 while powering on the printer. It beeps
once after implementing the paper detection action, while LED"DATA" blinks and other LEDs light up,
to indicate the activation of Calibrations mode.
2) Close the cover, the printer resets. Press 【OFFLINE】, the printer beeps once. All LEDs light up.
3) Press 【USER2】 , the printer beeps once. The left margin setting mode is activated. Load an A4 paper.
13 patterns of adjustment are printed and ejects the paper. An adjustment value "6" (6
made into a center value.
4) Now each press of 【USER1】 or 【USER2】 to reduce or increase the left margin, respectively, by
one unit of 1/60 inch.(Note: Beeps 3 times when reaches the limits.)
5) Repeat 3 to 4.
6) When satisfied with the left margin setting, press 【OFFLINE】 to permanently store the TOF .
Automatically, it switches to the Calibration menu.
7) Switch off the printer to exit from Calibration menu.
43
th
pattern) is
