TGW4/8 Gateway Series for Aeonix

2.7.3 Management System Type

After login, click the Advanced > System tab to open this interface.
SNMP configuration interface
Figure 2-27
SNMP Configuration Parameters
Table 2-22
Name
Signaling port
Server
Trap port
Notification
interval
TR069 configuration interface
Figure 2-28
Tadiran Telecom (TTL) L.P.
Description
Enter the SNMP local port. The default value is 2700.
If SNMP is selected, the following three parameters need to be specified.
Enter the address of the SNMP server.
Enter the port number of the SNMP server. The default value is 162.
The default value is 900 sec.
User Configuration Manual
53
