TGW4/8 Gateway Series for Aeonix
Name
*
Password
*
Inbound handle
*
Number
Voice prompt
Dialing tone
RFC6913
Registration
subscription
Polarity reversal
signal detection
Caller ID
detection
Outgoing call
barring
Echo cancellation
Connect signal
delay
Permanent
recording
Tadiran Telecom (TTL) L.P.
Description
If Registration is selected, the authentication password for register of this line must be
entered here.
Enter the authentication password for registration of this FXO line. Configure the
FXO line password as part of the account information, which is used for
authentication by Aeonix (no default value). It is formed with either numbers or
characters, and is case-sensitive.
The gateways provide three scenarios for handling incoming calls on the FXO trunk:
Binding: when a telephone call comes to the FXO port, the gateways will route the

call to a FXS port according to the DID number bound with the port.
Note: Setting a number to be bound is required or this setting is invalid.
Second-stage dialing: when a telephone call comes to the trunk port, the gateway

will play second dial prompt or tone as configured and route the call according to the
extension number entered.
Direct: the gateways will route the incoming call on FXO port n to FXS port n.FXO

ports map to FXS ports. For example, a call made to the first FXO port is forwarded
to the first FXS port.
Note: Direct applies only to a TGW having both FXO and FXS ports.
For Aeonix  Select Binding.
This option is shown when Binding is selected.
Fill in the number to be bound when a telephone call comes to this FXO Line port.
This means that an incoming trunk call will be directed to the binding number.
This option is shown when Second-stage dialing is selected.
Play the second dial prompt uploaded on Advanced > Greeting file page
This option is shown when Second-stage dialing is selected.
Play the second dial tone configured on Advanced > Tones page.
If this item is selected, the Fax over IP label carried in INVITE is supported.
The TGW periodically sends subscription messages to the SIP server. The period of
sending the subscription messages is the same as the Registration expiration in
Basic > SIP.
If a PSTN line supports reverse polarity, make the selection here. Or this setting is
invalid. By default, this is not selected.
Select to enable the detection function of caller ID for this FXO port. By default, this is
not selected.
Select if this FXO port bars the outgoing call service to the PSTN. By default, this is
not selected.
Select if echo cancellation is enabled for this FXO (Line). By default, this is selected.
After making an outgoing call from an FXO port, the gateway will send a 200 OK
message to the platform with a delay if this parameter is selected. If cleared, the system
sends a 200 OK message to the platform after off hook on the FXO port. Also see
Answer delay on the Trunk > Advanced page.
Select if the recording service is activated. By default, this is cleared (not selected).
