Auto Monitor - Net research NetProbe 2000 User Manual

6.3

Auto Monitor

Run the AUTO MONITOR application to automatically check the tested T1 signal for the following Parameter categories:
Line Errors, Alarms, Errors, G.826 analysis and RFC1406 analysis.. For each, the status is displayed along with failure
details. The indicators at the top display the current and historical state of SIGNAL/FRAME/ALARM/ERROR events.
You can display additional sub-detail metrics for each category by clicking on a Parameter category name button. For
instance, click on the Line button to display detail metrics for Code errors, Frequency and more. See example below.
73
Tips:
Click in the histogram column to
display a histogram for the
corresponding metric.
Click a box under
SIGNAL/FRAME/ALARM/ERROR
to reset the history of that
event.
Green arrows at the bottom
may be used to display
additional information for a
metric category.
