16.3.1 Preferences

To configure preferences, click on the button that is localized on Contacts, Keypad and Call log tab. The preference
window is not accessible during a phone call. Preferences are divided into four groups: Network, Multimedia, Accounts,
Codecs.
Network Tab
Send DTMFs as SIP Info - determines which technique should be used for carrying the
DTMF information. If option is checked, the DTMF information is actually represented
numerically and not by tone. If option is unchecked (by default), then tones are
transported using the Real Time Protocol (RTP RCF2833).
SIP protocol and port – defines the protocol and port that is used for SIP traffic. You can
select three protocols: UDP, TCP, TLS. Default port numbers are 5060 (UDP, TCP) and
5061 (TLS)
Audio RTP/UDP port – defines the port number used by the RTP protocol for audio.
Default value is 7078.
304
