GENERAL Tab

•
Select Test Level as Layer 1 Framed, Layer 2, Layer 3 or Layer 4)
•
Select Test Frame size to be test as 64, 128, 256, 512, 1024 or 1518 bytes.
You can also enter a value from 64 to 9600 by clicking on an entry box.
•
Tap on MAC-IP-UDP boxes to set MAC addresses (Layer 2-4) and IP
addresses, TTL, TOS, Protocol, Source and Destination Ports (Layer 3-4).
Each is illustrated below:
195
