Alarms Tab - Net research NetProbe 2000 User Manual

ALARMS Tab

Click on this tab to display detected Alarms. The alarms are displayed with a green or red background as described
below; otherwise, they will be displayed with a gray background. The error count, amount of time in seconds that
alarm remained raised during the test and total number of times the alarm event occurred are also displayed.
•
LOS (Los Of Signal): indicates a loss of signal on the optical port
•
Link Down: indicates that the Ethernet connection is down.
•
CRC: displays total number of received frames with invalid CRC
LED Color
No error pending
At least one error present in last second
Meaning
242
