Dynacode II Series
Speed
(intermittent
mode only)
Contrast
Ribbon control
X displacement
08.16

9.3 Print Settings

Indication of print speed in mm/s (see Technical Data, page 19). The
print speed can be determined for each print order anew.
The setting of print speed affects also the test prints.
Value range: 50 ... 600 mm/s
Step size: 10 mm/s
Indication of value to set the print intensity when using different
materials, print speeds or printing contents.
Value range: 10% ... 200 %.
Step size: 10%
Examination if the transfer ribbon roll is empty and/or if the ribbon was
torn at the unwinding roll.
Off: The ribbon control is deselected, i.e. the printer continues without
an error message.
On: The ribbon control is selected, i.e. the current print order is
interrupted and an Error Message appears at the printer display.
Strong sensibility: The printer reacts immediately to the end of the
transfer ribbon.
Weak sensibility: The printer reacts at approx. 1/3 more slowly to the
end of the transfer ribbon.
Displacement of the complete print transverse to the paper direction.
The displacement is possible only up to the edges of the printing zone
and is determined by the width of the focal line in printhead.
Value range: −90.0 ... +90.0.
Operating Manual
Function Menu
51
