Flexicode
Speed
(intermittent
mode only)
Contrast
Ribbon control
X displacement
11.19

7.3 Print Settings

Switch on the control unit and the display shows the main menu.
Press the key to access the function menu.
Press the key to select the menu Print settings.
Indication of print speed in mm/s (see Technical Data, page 19). The
print speed can be determined for each print order anew.
The setting of print speed affects also the test prints.
Value range: 50 ... 400 mm/s
Step size: 10 mm/s
Indication of value to set the print intensity when using different
materials, print speeds or printing contents.
Value range: 10 % ... 200 %.
Step size: 10 %
Press the key to move to the next menu item.
Examination if the transfer ribbon roll is empty and/or if the ribbon was
torn at the unwinding roll. The current print order is interrupted and an
Error Message appears at the printer display.
Off: The ribbon control is deselected, i.e. the printer continues without
an error message.
On, weak sensibility (default): The printer reacts at approx. 1/3
more slowly to the end of the transfer ribbon.
On, strong sensibility: The printer reacts immediately to the end of
the transfer ribbon.
Press the key to move to the next menu item.
Displacement of the complete print transverse to the paper direction.
The displacement is possible only up to the edges of the printing zone
and is determined by the width of the focal line in printhead.
Value range: −90.0 ... +90.0.
