10.5 Navigation Zones

Position
indication
Figure 48
Navigation
zone 1
The respective navigation zone can be moved with an appropriate
swipe movement from top to bottom or from the bottom up.
NOTE!
With the used resistive touch screen variant a certain pressure
on the display is needed.
It is not possible to navigate on the display with the swipe
movement to the left and right with a finger (well-known from
smartphones).
The position indications signalise the detail of the total list currently
visible. If no position indication is visible then the total list can be
displayed on the display. A swipe movement from top to bottom
and/or from the bottom up is not possible.
Operating Manual
Navigation
zone 2
Touch-Screen Display
Position
indication
