Machine Parameters (Intermittent Mode) - Carl Valentin Dynacode II Series Operating Manual

Function Menu
Resolution
Material speed
Mode
Back speed
54
Encoder resolution / material feed per encoder rotation
Indication of resolution of used encoder and material feed per rotation
of encoder in mm. These settings help measuring the material speed.
The material feeding per encoder rotation corresponds for instance, in
a 1:1 translation between the encoder and the roller, to the roller
circumference.
Indication of material speed (only for reading purposes).

9.5 Machine Parameters (Intermittent Mode)

No. of pieces A print order with a defined number of pieces is
transferred. After the generating process the target
number and the actual number of pieces is shown in
the display. A cycle is started via signal input 1 or
with key
of pieces is increased by the number of printed
layouts. In case the target number of pieces is
reached the print order is finished and the display
shows again the main menu.
Continuous A print order is transferred. After the generating
process the number of printed layouts is shown in
the display. A cycle is started via signal input 1 or
with key
printed layouts is increased. The print order is active
as long as it is terminated by the user or in case of
new data transmission.
Test mode
This operating mode corresponds to mode 2. After
the return of the print unit to the zero point of the
machine, however, internally a further cycle is
started (endurance test).
Direct start A print order is transferred. After termination of
generating process the print order is executed
without an external signal.
Indication of back speed of print mechanics after print end in mm/s.
Each cycle of the machine consists of printing and return to the zero
point of machine. It is possible to set the print speed and back speed
separately.
Because of this value you can select for low machine clock cycles an
operating method which saves the material and increases in this way
the life of the printhead.
Because of the mass moment of inertia it could be better to reduce the
speed at an installation position of the print unit at >30° horizontal.
Value range: 50 ... 600 mm/s.
Operating Manual
Dynacode II Series
. With each cycle the actual number
. With each cycle the number of
