Hardware Installation and Reference Guide
2)
Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-5.
Figure 3-5 Aligning the Square Feet with the Mounting Holes
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3)
Slide the AP into the holes in the reverse direction against the arrow on the mounting bracket until it clicks into place.
Note: the "Ruijie" logo is facing up. See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
Installing the Access Point
·
