A Pressure Regulator
B Y-Filter
C Universal Male Adapter
D ½" Distribution/Supply Line
E Threaded Coupler (sold separately)
2 Run Distribution/Supply Line
next to plants, shrubs and trees you
intend to water. Next install a ½" End
Cap. Use ½" Loop Stakes to hold the
line in place.
3 Hole Punch—Punch a hole in the
½" Distribution/Supply Line for each
shrub or tree. Next insert a ¼" Barbed
Coupler into each hole.
4 Connect the ¼" Distribution/Supply Line to each of the exposed Barbed
Couplers and run it to the base of each shrub or tree. Cut tubing to desired
length.
IMPORTANT: A single ¼" Distribution/Supply Line should not
exceed 30'.
26
SECTION
B .
.
E C
.
A
3
Orbit DripMaster | Installation Guide
® ®
5 Remove the ½" End Cap and turn on water to flush ½" Distribution/
8
Supply Line, then replace cap to flush ¼" Distribution/Supply Lines.
6 Attach a Pressure Compensating Dripper to each ¼" Distribution/
Supply Line. To hold dripper in place, next to the base of the shrub or tree,
use a Tube Stake.
Note: More than one ¼"Distribution/
Supply Line (with Pressure
Compensating Dripper) may be
required for large trees or shrubs.
IMPORTANT: Do not attach
more than 57 2-GPH Pressure
Compensating Drippers to a single ½"
D
Distribution/Supply Line
.
.
.
.
6
.
.
A Tube Stake
4
B Pressure Compensating Dripper
C ¼" Distribution/Supply Line
Supplies needed:
- ½" Universal Male Adapter (part # 67454 or 67470)
- ½" Distribution/Supply Tubing (part #67345 or 67346)
- ½" End Cap (part # 67462, 67444 or 67468)
- ½" Loop Stake (part # 61442P, 65731 or 66731)
- Punch Tool (part # 61285 or 67756)
- ¼" Barbed Couplers (part # 66402 or 67402) or the ¼" Barbed Assortment
Pack (part # 66431 or 67431)
- ¼" Distribution/Supply Tube (part # 67300, 67301 or 67303)
- Tube Stakes (part # 65721or 66721)
- Pressure Compensating Dripper (part # 66205, 67205, 66206, 67206 or
68206)
