Configuring BGP
Command
Step 5
set comm-list list-num delete
Step 6
exit
Step 7
ip bgp-community new-format
Step 8
end
Step 9
show ip bgp community
Step 10 copy running-config startup-config

Configuring BGP Neighbors and Peer Groups

Often many BGP neighbors are configured with the same update policies (that is, the same outbound
route maps, distribute lists, filter lists, update source, and so on). Neighbors with the same update
policies can be grouped into peer groups to simplify configuration and to make updating more efficient.
When you have configured many peers, we recommend this approach.
To configure a BGP peer group, you create the peer group, assign options to the peer group, and add
neighbors as peer group members. You configure the peer group by using the neighbor router
configuration commands. By default, peer group members inherit all the configuration options of the
peer group, including the remote-as (if configured), version, update-source, out-route-map,
out-filter-list, out-dist-list, minimum-advertisement-interval, and next-hop-self. All peer group members
also inherit changes made to the peer group. Members can also be configured to override the options that
do not affect outbound updates.
To assign configuration options to an individual neighbor, specify any of these router configuration
commands by using the neighbor IP address. To assign the options to a peer group, specify any of the
commands by using the peer group name. You can disable a BGP peer or peer group without removing
all the configuration information by using the neighbor shutdown router configuration command.
Beginning in privileged EXEC mode, use these commands to configure BGP peers:
Command
Step 1
configure terminal
Step 2 router bgp autonomous-system
Step 3 neighbor peer-group-name peer-group
Step 4 neighbor ip-address peer-group
peer-group-name
Step 5
neighbor {ip-address | peer-group-name}
remote-as number
Step 6 neighbor {ip-address | peer-group-name}
description text
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
1-60
Purpose
(Optional) Remove communities from the community attribute of an
inbound or outbound update that match a standard or extended
community list specified by a route map.
Return to global configuration mode.
(Optional) Display and parse BGP communities in the format AA:NN.
A BGP community is displayed in a two-part format 2 bytes long. The
Cisco default community format is in the format NNAA. In the most
recent RFC for BGP, a community takes the form AA:NN, where the
first part is the AS number and the second part is a 2-byte number.
Return to privileged EXEC mode.
Verify the configuration.
(Optional) Save your entries in the configuration file.
Purpose
Enter global configuration mode.
Enter BGP router configuration mode.
Create a BGP peer group.
Make a BGP neighbor a member of the peer group.
Specify a BGP neighbor. If a peer group is not configured with a
remote-as number, use this command to create peer groups
containing EBGP neighbors. The range is 1 to 65535.
(Optional) Associate a description with a neighbor.
Chapter 1 Configuring IP Unicast Routing
