12.4 Removing and installing
the door
You can remove the door and the
internal glass panels to clean it. The
number of glass panels is different for
different models.
1. Open the door fully.
2. Fully press the clamping levers (A) on
the two door hinges.
3. Close the oven door to the first
opening position (approximately 70°
angle).
4. Hold the door with one hand on each
side and pull it away from the
appliance at an upwards angle.
5. Put the door with the outer side
down on a soft cloth on a stable
surface. This is to prevent scratches.
6. Hold the door trim (B) on the top
edge of the door at the two sides
EURO Appliances - euappliances.info
To stop the pyrolytic
cleaning before it is
completed, deactivate the
appliance.
WARNING!
After the function is
completed, the appliance is
very hot. Let it cool down.
There is a risk of burns.
After the function is
completed, the door stays
locked for the cool down
phase. Some of the
appliance functions are not
available during the cool
down phase.
WARNING!
Be careful when you remove
the door from the appliance.
The door is heavy.
A
and push inwards to release the clip
seal.
2
B
7. Pull the door trim to the front to
remove it.
8. Hold the door glass panels on their
top edge one by one and pull them
up out of the guide.
9. Clean the glass panel with water and
soap. Dry the glass panel carefully.
When the cleaning is completed, install
the glass panels and the door. Do the
above steps in the opposite sequence.
Install the smaller panel first, then the
larger.
12.5 Replacing the lamp
Put a cloth on the bottom of the interior
of the appliance. It prevents damage to
the lamp glass cover and the cavity.
A
1. Deactivate the appliance.
2. Remove the fuses from the fuse box
or deactivate the circuit breaker.
The top lamp
1. Turn the lamp glass cover
counterclockwise to remove it.
ENGLISH
1
WARNING!
Danger of electrocution!
Disconnect the fuse before
you replace the lamp.
The lamp and the lamp glass
cover can be hot.
41
