- Page 1 Fluoroscopy Stretcher Model 1080 White letters and outline with transparent rectangle Operations Manual For parts or technical assistance: USA: 1-800-327-0770 2011/12 A.0 1080-009-001 REV A www.stryker.com...
-
Page 3: Table Of Contents
International Warranty Clause............www.stryker.com 1080-009-001 REV A... -
Page 4: Symbols And Definitions
NOTE Provides special information to make maintenance easier or important instructions clearer. Return To Table of Contents 1080-009-001 REV A www.stryker.com... -
Page 5: Introduction
Introduction This manual is designed to assist you with the operation of Stryker Model 1080 Fluoroscopy Stretcher. Read this manual thoroughly before using the equipment or beginning maintenance on it. To ensure safe operation of this equipment, it is recommended that methods and procedures be established for educating and training staff on the safe operation of this stretcher. -
Page 6: Summary Of Safety Precautions
• Some cleaning products are corrosive in nature and may cause damage to the product if used improperly. If the products suggested above are used to clean Stryker patient handling equipment, measures must be taken to ensure that the stretcher is wiped with a damp cloth soaked in clean water and thoroughly dried following cleaning. -
Page 7: Operation Guide
Always apply the brakes when a patient is getting on or off the stretcher. Push on the stretcher to ensure that the brakes are securely locked. Always engage the brakes unless the stretcher is being moved. Injury could result if the stretcher moves while a patient is getting on or off the stretcher. Return To Table of Contents www.stryker.com 1080-009-001 REV A... -
Page 8: Operating The Siderails
To avoid injury or damage to the equipment, do not allow the siderail to lower on its own. Make sure that the siderail latching mechanism is working properly at all times. If it is not, see the stretcher maintenance manual for ”Siderail Latch Adjustment”. Return To Table of Contents 1080-009-001 REV A www.stryker.com... -
Page 9: Operating The Fowler
• Keep hands/fingers clear of the area around the fowler release handle and the fowler frame when lowering the fowler. Injury could result if care is not taken when lowering the fowler. If the pneumatic fowler is difficult to operate, see the stretcher maintenance manual for ”Pneumatic Fowler Adjustment”. Return To Table of Contents www.stryker.com 1080-009-001 REV A... -
Page 10: Operating The Two-Stage Permanently Attached I.v. Pole
• To avoid damage while transporting the stretcher, verify that the I.V. pole is at a low enough height to allow it to safely pass through door openings and under light fixtures. • Do not use the I.V. pole as a push/pull device because equipment damage could occur. Return To Table of Contents 1080-009-001 REV A www.stryker.com... -
Page 11: Optional Accessories
Optional Accessories The accessories listed below can be purchased and installed on the Model 1080 Fluoroscopy Stretcher. Accessory Part Number Page Footboard/Chart Holder 1080-134-000 page 12 I.V. Pole, Removable 0390-025-000 page 13 Oxygen Bottle Holder, Upright 1020-130-000 page 13 Restraints, Ankle... -
Page 12: Using The Footboard/Chart Holder
(A) into the corresponding holes located at the foot end of the stretcher. CAUTION Do not use the footboard/chart holder as a push/pull device because equipment damage could occur. Footboard/Chart Holder Return To Table of Contents 1080-009-001 REV A www.stryker.com... -
Page 13: Operating The Removable I.v. Pole
40 lb. in the upright oxygen bottle holder. • Do not use the upright oxygen bottle holder as a push/pull device because equipment damage could occur. Upright Oxygen Bottle Holder Return To Table of Contents www.stryker.com 1080-009-001 REV A... -
Page 14: Using The Restraint Straps
This unit allows the use of ankle, chest, wrist, and body restraints. See the figure below for restraint strap attachment points. Do not attach restraints straps to the siderail. Stryker makes no recommendation for the use of restraints. Restraint Strap Locations WARNING • Physical restraints, even if properly secured, may result in serious harm to patients and caregivers. -
Page 15: Cleaning
Some cleaning products are corrosive in nature and may cause damage to the product if used improperly. If the products suggested above are used to clean Stryker patient handling equipment, measures must be taken to ensure that the stretcher is wiped with a damp cloth soaked in clean water and thoroughly dried following cleaning. Failure to properly rinse and dry the stretcher will leave a corrosive residue on the surface of the stretcher, possibly causing premature corrosion of critical components. -
Page 16: Preventative Maintenance
Preventative Maintenance At a minimum, preventative maintenance should be performed annually. A preventative maintenance program should be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently based on the usage level of the product. -
Page 17: Warranty
Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective. If requested by Stryker, products or parts for which a warranty claim is made shall be returned prepaid to the factory. Any improper use or any alteration or repair by others in such manner as in Stryker’s judgment affects the product materially and... -
Page 18: Service Contract Programs
Service during regular business hours (8-5) * Replacement parts and labor for products under PM contract will be discounted. ** Does not include any disposable items, I.V. poles (except for Stryker permanently attached poles), mattresses, batteries, or damage resulting from abuse. - Page 20 United States Stryker Medical 3800 E. Centre Ave., Portage, Michigan USA 49002 European Representative Stryker France S.A.S. ZAC - avenue Satolas Green 69881 MEYZIEU Cedex France 2011/12 1080-009-001 REV A www.stryker.com...
