• DSP-2 UNIT
RESET IC
(IC8205)
RESET IC
(IC8204)
AF SW
(IC8217)
2-5
+1.2 V REGULATOR
(IC8203)
DSP
(IC8201)
AF SW
(IC8216)
USB HUB
(IC8207)
USB BRIDGE
(IC8209)
USB BRIDGE
(IC8210)
+3.3 V REGURATOR
(IC8215)
USB CODEC
(IC8208)
