• PA UNIT
RF AMP
(Q4002)
PRE-DRIVE AMP
(Q4003)
COOLING FAN DRIVER
(Q4001)
COOLING FAN DRIVER
(Q4008)
POWER DIVIDER
(L4009)
VARISTOR-1 UNIT
POWER AMP
(Q4007)
POWER COMBINER
(L4014)
2-3
BIAS CONTROLLER
(for POWER AMP)
(IC4002)
SERIAL TO PARALLE
CONVERTER
(IC5001)
VARISTOR-2 UNIT
POWER AMP
(Q4006)
