Icom IC-F8100 Service Manual page 40

[VARISTOR-1 UNIT]
REF PARTS
NO. NO.
D6431 1750000940 S.DIO 1SS400 TE61
C6431 4030008920 S.CER C1608 JB 1H 473K-T
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
[VARISTOR-2 UNIT]
H/V REF PARTS
NO. NO.
3.5/13.4 D6431 1750000940 S.DIO
3.7/11.7 C6431 4030008920 S.CER C1608 JB 1H 473K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-12
DESCRIPTION M.
1SS400 TE61 T
T
S.=Surface mount
H/V
LOCATION
3.5/13.4
3.7/11.7
