[DSP-1 UNIT]
REF PARTS
NO. NO.
C3702 4030019560 S.CER GRM21BB31C106KE15L
C3703 4030018580 S.CER C1608 CH 1H 821J-T
C3704 4030018580 S.CER C1608 CH 1H 821J-T
C3705 4030017760 S.CER C1005 JB 1H 222K-T
C3706 4030017760 S.CER C1005 JB 1H 222K-T
C3707 4030011340 S.CER C1608 CH 1H 471J-T
C3708 4030011340 S.CER C1608 CH 1H 471J-T
C3709 4030017420 S.CER C1005 CH 1H 470J-T
C3710 4030019990 S.CER C1005 JB 1C 104K-T
C3711 4030019990 S.CER C1005 JB 1C 104K-T
C3712 4030019560 S.CER GRM21BB31C106KE15L
C3713 4030019560 S.CER GRM21BB31C106KE15L
C3715 4030017380 S.CER C1005 CH 1H 050B-T
C3716 4030019990 S.CER C1005 JB 1C 104K-T
C3718 4030016790 S.CER C1005 JB 1E 103K-T
C3719 4030016790 S.CER C1005 JB 1E 103K-T
C3720 4030018980 S.CER C1608 JB 1H 104K-T
C3721 4030018980 S.CER C1608 JB 1H 104K-T
C3723 4030018980 S.CER C1608 JB 1H 104K-T
C3725 4030019490 S.CER C2012 JB 1A 106K-T
C3726 4030019990 S.CER C1005 JB 1C 104K-T
C3727 4030017420 S.CER C1005 CH 1H 470J-T
C3728 4030017420 S.CER C1005 CH 1H 470J-T
C3729 4030017420 S.CER C1005 CH 1H 470J-T
C3730 4030017780 S.CER C1005 JB 1H 472K-T
C3731 4030016790 S.CER C1005 JB 1E 103K-T
C3732 4030019460 S.CER C1608 JB 0J 106M-T
C3733 4030019460 S.CER C1608 JB 0J 106M-T
C3734 4030021240 S.CER C1005 JB 1C 105K-T
C3735 4030017490 S.CER C1608 JB 1A 105K-T
C3736 4030021240 S.CER C1005 JB 1C 105K-T
C3737 4550007670 S.TAN F931C105MAABMA
C3741 4510008650 S.ELE EEEFK1C221P
C3742 4030019460 S.CER C1608 JB 0J 106M-T
C3743 4030006880 S.CER C1608 JB 1H 472K-T
RL3001 6310000110 S.REL AGQ200S12
J3001 6510021722 S.CON 30FLT-SM2-TB(LF)(SN)(M)
J3002 6510021722 S.CON 30FLT-SM2-TB(LF)(SN)(M)
J3006 6510018961 S.CON B2B-PH-SM4-TB(LF)(SN)
J3007 6510026650 S.CON BM12B-SRSS-TBT(LF)(SN)
J3303 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M)
J3305 6510024751 S.CON (G)BM07B-SRSS-TB(LF)(SN)
J3306 6510025990 S.CON (G)BM05B-SRSS-TB(LF)(SN)
J3307 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M)
J3308 6510018961 S.CON B2B-PH-SM4-TB(LF)(SN)
EP3005 6910012350 S.BEA MMZ1608Y 102BT
EP3006 6910012350 S.BEA MMZ1608Y 102BT
EP3007 6910012350 S.BEA MMZ1608Y 102BT
EP3011 6910012350 S.BEA MMZ1608Y 102BT
EP3012 6910012350 S.BEA MMZ1608Y 102BT
EP3021 6910012350 S.BEA MMZ1608Y 102BT
EP3023 6910012350 S.BEA MMZ1608Y 102BT
EP3024 6910015970 S.BEA MMZ1608B 301CT-AS
EP3025 6910015970 S.BEA MMZ1608B 301CT-AS
EP3026 6910015970 S.BEA MMZ1608B 301CT-AS
EP3027 6910015970 S.BEA MMZ1608B 301CT-AS
EP3028 6910012350 S.BEA MMZ1608Y 102BT
EP3029 6910012350 S.BEA MMZ1608Y 102BT
EP3030 6910015970 S.BEA MMZ1608B 301CT-AS
EP3031 6910012350 S.BEA MMZ1608Y 102BT
EP3032 6910012350 S.BEA MMZ1608Y 102BT
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
T
T
T
T
T
T
T
B
B
B
B
T
T
B 128.2/45.5
B 128.7/40.4
B 132.6/27.6
B 128.1/22.0
B 130.2/26.8
B 130.4/28.4
B 126.8/27.9
T 119.7/39.2
T 121.4/39.2
T 123.1/39.2
B 118.7/38.7
B 118.8/36.8
B 106.8/12.3
B 115.0/12.8
B 101.2/21.4
B 111.2/12.9
B 113.3/21.6
T
T 105.8/27.4
B 104.6/21.7
B
T 124.6/13.8
T 138.6/23.5
T 138.6/16.7
T 125.5/27.5
T 125.5/36.5
T
T 133.3/44.1
T 122.1/44.1
T 116.0/19.6
T 143.9/30.8
B 120.6/31.1
B 121.8/31.1
B 123.7/34.4
B 125.4/31.1
B 130.5/40.0
T 127.3/21.4
B 127.1/26.9
B 123.0/43.0
B 121.0/39.0
B 122.4/39.0
B 119.7/39.0
B 123.0/31.1
B 124.2/31.1
B 124.3/43.0
T 134.0/36.5
T 118.8/31.8
[DSP-2 UNIT]
H/V REF PARTS
NO. NO.
50.2/37.3 IC8001 1180004180 S.REG ADP2323ACPZ-R7 <FE>
39.5/18.4 IC8003 1130012850 S.IC
39.2/21.5 IC8201 1140015432 S.IC
43.9/37.1 IC8202 1130017091 S.IC
46.0/38.8
45.1/35.8 IC8203 1180003410 S.REG BD12KA5FP-E2
48.1/35.4 IC8204 1130006551 S.IC
42.3/17.9 IC8205 1110005851 S.IC
49.0/11.7 IC8206 1180004190 S.REG LT8582IDKD#TRPBF
55.6/16.5 IC8207 1190002911 S.IC
47.6/12.5 IC8208 1190002240 S.IC
57.0/15.6 IC8209 1190002730 S.IC
18.7/18.7 IC8210 1190002730 S.IC
43.3/19.8 IC8211 1130007111 S.IC
IC8212 1130007111 S.IC
IC8213 1130013010 S.IC
IC8214 1180003480 S.REG NJU7772F33-TE1-#ZZZB
IC8215 1180003480 S.REG NJU7772F33-TE1-#ZZZB
IC8216 1130008511 S.IC
IC8217 1130008511 S.IC
IC8218 1130007111 S.IC
Q8001 1560001980 S.FET
Q8002 1560001980 S.FET
Q8003 1550000230 S.FET
Q8004 1590003680 S.TRA
Q8005 1590003680 S.TRA
Q8006 1590004390 S.TRA
Q8007 1590004390 S.TRA
Q8008 1590003680 S.TRA
70.0/26.4 Q8009 1590003680 S.TRA
Q8010 1590002310 S.TRA
Q8011 1590003930 S.TRA
94.5/4.0 Q8013 1590004390 S.TRA
D8001 1790001450 S.DIO
D8002 1750000540 S.DIO
D8003 1750001180 S.DIO
D8004 1750001180 S.DIO
D8005 1750002210 S.DIO
D8006 1750002210 S.DIO
D8007 1750002210 S.DIO
16.4/4.5
FI8201 2040000790 S.LC
FI8202 2040000790 S.LC
X1 6050012970 S.XTA
X2 6050012770 S.XTA
L8001 6190002070 S.COI
L8002 6200009491 S.COI
L8003 6200009491 S.COI
L8004 6200009491 S.COI
L8005 6200009491 S.COI
L8006 6200009491 S.COI
L8201 6200011900 S.COI
L8202 6200011900 S.COI
L8203 6200003281 S.COI
L8204 6200005011 S.COI
L8205 6200005011 S.COI
L8206 6200009491 S.COI
R8001 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8002 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8003 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8004 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R8005 7030005220 S.RES ERJ2GEJ 223 X (22K)
R8006 7030005530 S.RES ERJ2GEJ 100 X (10)
R8007 7030007340 S.RES ERJ2GEJ 153 X (15K)
R8008 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R8009 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8010 7030010040 S.RES ERJ2GEJ-JPW
R8011 7030005080 S.RES ERJ2GEJ 823 X (82K)
R8012 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R8013 7030005050 S.RES ERJ2GEJ 103 X (10K)
R8014 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8015 7030005290 S.RES ERJ2GEJ 682 X (6.8K)
R8016 7030004980 S.RES ERJ2GEJ 101 X (100)
R8017 7030005080 S.RES ERJ2GEJ 823 X (82K)
R8018 7030010040 S.RES ERJ2GEJ-JPW
R8019 7030005110 S.RES ERJ2GEJ 224 X (220K)
R8020 7030005110 S.RES ERJ2GEJ 224 X (220K)
R8021 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8022 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8023 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8024 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8025 7030005090 S.RES ERJ2GEJ 104 X (100K)
R8201 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R8202 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R8203 7030010040 S.RES ERJ2GEJ-JPW
R8204 7030007260 S.RES ERJ2GEJ 330 X (33)
R8205 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8206 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8207 7030005240 S.RES ERJ2GEJ 473 X (47K)
R8208 7030010040 S.RES ERJ2GEJ-JPW
R8209 7030010040 S.RES ERJ2GEJ-JPW
R8210 7030010040 S.RES ERJ2GEJ-JPW
R8211 7030010040 S.RES ERJ2GEJ-JPW
R8212 7030005240 S.RES ERJ2GEJ 473 X (47K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-15
DESCRIPTION M.
B
SN74LVC3G34DCUR B
TMS320C6747DZKBT3 T
EN29LV040A-70SCP
(SX-3500C-1) B
T
TC7S08FU(TE85RF) T
S-80830CNMC-B8P-T2G T
B
TUSB2046BIVFRG4 T
PCM2901E/2K T
CP2102-GMR <MAC> T
CP2102-GMR <MAC> T
TC7W04FU(TE12LF) B
TC7W04FU(TE12LF) B
SN74AHC1G08DCK3 T
B
T
TC7W53FU(TE12LF) T
TC7W53FU(TE12LF) T
TC7W04FU(TE12LF) B
SSM3K131TU(TE85L) B
SSM3K131TU(TE85L) B
SSM3J117TU(TE85L) B
KRC402 RTK/P T
KRC402 RTK/P T
DMG504010R B
DMG504010R B
KRC402 RTK/P T
KRC402 RTK/P T
DTC114EE TL B
UMD22N TR T
DMG504010R B
RB160L-40 TE-25 B
RB060L-40 TE-25 B
KDS122 RTK/P B
KDS122 RTK/P B
DA2S00100L B
DA2S00100L B
DA2S00100L B
EXCCET103U T
EXCCET103U T
CR-890 TSS-2 6 MHz B
CR-870 DSX321G 12 MHz<KDS> T
7E08L-100M-RA-0231 T
CDRH6D28NP-100NCI B
CDRH6D28NP-100NCI B
CDRH6D28NP-100NCI T
CDRH6D28NP-100NCI T
CDRH6D28NP-100NCI B
LQH43CN100K03L T
LQH43CN100K03L T
NLV25T-2R2J B
NLV25T-100J T
NLV25T-100J T
CDRH6D28NP-100NCI T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
B
B
B
B
S.=Surface mount
H/V
LOCATION
74.7/11.8
78.8/17.8
28.5/28.3
15.4/27.6
13.1/30.1
45.2/16.7
41.1/16.7
95.3/14.6
61.3/33.6
102.1/27.3
77.8/32.5
88.2/31.7
68.0/23.5
76.3/23.5
101.5/34.9
65.4/34.9
96.5/38.5
52.3/23.0
52.3/16.1
91.9/24.3
72.7/6.7
76.8/6.7
87.5/17.8
75.4/28.3
85.8/27.3
68.0/26.5
76.3/26.5
104.8/34.9
88.8/26.6
60.2/13.2
37.3/18.3
91.9/27.4
107.4/13.2
86.8/13.5
61.4/26.9
61.4/29.4
68.8/28.4
77.0/28.4
91.9/29.3
44.2/25.2
38.9/22.7
52.7/39.0
110.1/27.9
57.1/9.5
85.2/6.3
93.9/6.3
93.1/4.3
83.1/4.3
63.2/7.1
43.0/31.1
43.4/20.3
22.1/18.1
72.0/32.6
82.2/30.7
66.4/5.3
74.7/16.2
73.0/18.0
76.6/15.1
70.7/14.0
69.8/14.0
79.0/15.1
70.2/12.8
70.3/15.3
68.6/12.8
79.1/12.6
80.7/12.6
78.2/13.8
79.1/13.8
73.0/16.2
88.9/15.8
90.5/17.2
83.6/17.8
85.2/17.8
91.9/16.3
91.0/11.3
99.3/18.3
98.4/12.6
90.3/14.0
102.8/15.2
104.5/15.2
34.5/29.8
34.5/28.9
35.5/27.7
33.4/23.8
38.3/38.5
36.9/38.5
34.3/38.5
35.6/38.5
33.4/24.9
33.4/20.9
33.4/21.8
24.7/18.5
