Icom IC-F8100 Service Manual page 34

[MAIN UNIT]
REF PARTS
NO. NO.
C1432 4030007090 S.CER C1608 CH 1H 470J-T
C1433 4030017650 S.CER C1005 CH 1H 270J-T
C1434 4030007080 S.CER C1608 CH 1H 390J-T
C1435 4030007070 S.CER C1608 CH 1H 330J-T
C1436 4030007140 S.CER C1608 CH 1H 121J-T
C1437 4030017400 S.CER C1005 CH 1H 220J-T
C1439 4030007050 S.CER C1608 CH 1H 220J-T
C1440 4030006880 S.CER C1608 JB 1H 472K-T
C1442 4030007030 S.CER C1608 CH 1H 150J-T
C1443 4030018980 S.CER C1608 JB 1H 104K-T
C1444 4030017420 S.CER C1005 CH 1H 470J-T
C1445 4030017390 S.CER C1005 CH 1H 180J-T
C1446 4030018980 S.CER C1608 JB 1H 104K-T
C1447 4030006880 S.CER C1608 JB 1H 472K-T
C1448 4030017650 S.CER C1005 CH 1H 270J-T
C1450 4030017780 S.CER C1005 JB 1H 472K-T
C1451 4030017500 S.CER C1005 CH 1H 560J-T
C1452 4030013960 S.CER C1005 JB 1C 473K-T
C1453 4030006880 S.CER C1608 JB 1H 472K-T
C1454 4030017780 S.CER C1005 JB 1H 472K-T
C1455 4030007170 S.CER C1608 CH 1H 221J-T
C1456 4030006880 S.CER C1608 JB 1H 472K-T
C1457 4030017500 S.CER C1005 CH 1H 560J-T
C1459 4030017780 S.CER C1005 JB 1H 472K-T
C1460 4030019990 S.CER C1005 JB 1C 104K-T
C1461 4030007030 S.CER C1608 CH 1H 150J-T
C1462 4030006880 S.CER C1608 JB 1H 472K-T
C1463 4030006880 S.CER C1608 JB 1H 472K-T
C1464 4030017780 S.CER C1005 JB 1H 472K-T
C1465 4030017780 S.CER C1005 JB 1H 472K-T
C1466 4030006970 S.CER C1608 CH 1H 060D-T
C1467 4030017600 S.CER C1005 CH 1H 080C-T
C1468 4030016790 S.CER C1005 JB 1E 103K-T
C1469 4030017780 S.CER C1005 JB 1H 472K-T
C1470 4030017780 S.CER C1005 JB 1H 472K-T
C1471 4030016790 S.CER C1005 JB 1E 103K-T
C1472 4030018980 S.CER C1608 JB 1H 104K-T
C1473 4030018980 S.CER C1608 JB 1H 104K-T
C1474 4030007030 S.CER C1608 CH 1H 150J-T
C1475 4030006880 S.CER C1608 JB 1H 472K-T
C1476 4030017780 S.CER C1005 JB 1H 472K-T
C1477 4030019490 S.CER C2012 JB 1A 106K-T
C1478 4030006880 S.CER C1608 JB 1H 472K-T
C1479 4030006880 S.CER C1608 JB 1H 472K-T
C1480 4030017810 S.CER C1608 CH 1H 102J-T
C1481 4030006880 S.CER C1608 JB 1H 472K-T
C1482 4030006880 S.CER C1608 JB 1H 472K-T
C1483 4030018980 S.CER C1608 JB 1H 104K-T
C1484 4030007130 S.CER C1608 CH 1H 101J-T
C1485 4030017810 S.CER C1608 CH 1H 102J-T
C1486 4030007140 S.CER C1608 CH 1H 121J-T
C1487 4030019090 S.CER C2012 JB 1C 225M-T
C1488 4030018980 S.CER C1608 JB 1H 104K-T
C1489 4030017780 S.CER C1005 JB 1H 472K-T
C1490 4030006880 S.CER C1608 JB 1H 472K-T
C1491 4030019490 S.CER C2012 JB 1A 106K-T
C1492 4030006880 S.CER C1608 JB 1H 472K-T
C1493 4030019990 S.CER C1005 JB 1C 104K-T
C1494 4030007150 S.CER C1608 CH 1H 151J-T
C1495 4030007130 S.CER C1608 CH 1H 101J-T
C1496 4030007150 S.CER C1608 CH 1H 151J-T
C1497 4030018980 S.CER C1608 JB 1H 104K-T
C1498 4030007150 S.CER C1608 CH 1H 151J-T
C1499 4030018980 S.CER C1608 JB 1H 104K-T
C1500 4030006880 S.CER C1608 JB 1H 472K-T
C1501 4030007150 S.CER C1608 CH 1H 151J-T
C1502 4030018980 S.CER C1608 JB 1H 104K-T
C1503 4030007140 S.CER C1608 CH 1H 121J-T
C1504 4030007130 S.CER C1608 CH 1H 101J-T
C1505 4030018980 S.CER C1608 JB 1H 104K-T
C1506 4030006880 S.CER C1608 JB 1H 472K-T
C1507 4030018980 S.CER C1608 JB 1H 104K-T
C1508 4030018980 S.CER C1608 JB 1H 104K-T
C1509 4510009820 S.ELE EEEFK1C470P
C1510 4030019990 S.CER C1005 JB 1C 104K-T
C1511 4030018980 S.CER C1608 JB 1H 104K-T
C1512 4030018980 S.CER C1608 JB 1H 104K-T
C1513 4030018980 S.CER C1608 JB 1H 104K-T
C1514 4030019460 S.CER C1608 JB 0J 106M-T
C1515 4030018980 S.CER C1608 JB 1H 104K-T
C1516 4030017490 S.CER C1608 JB 1A 105K-T
C1517 4030018980 S.CER C1608 JB 1H 104K-T
C1518 4030007090 S.CER C1608 CH 1H 470J-T
C1519 4030006880 S.CER C1608 JB 1H 472K-T
C1520 4030006880 S.CER C1608 JB 1H 472K-T
C1521 4030018980 S.CER C1608 JB 1H 104K-T
C1522 4030019460 S.CER C1608 JB 0J 106M-T
C1523 4030018980 S.CER C1608 JB 1H 104K-T
C1524 4030017490 S.CER C1608 JB 1A 105K-T
C1525 4030018980 S.CER C1608 JB 1H 104K-T
C1526 4030019460 S.CER C1608 JB 0J 106M-T
C1527 4030017490 S.CER C1608 JB 1A 105K-T
C1528 4030018980 S.CER C1608 JB 1H 104K-T
C1529 4030018980 S.CER C1608 JB 1H 104K-T
C1530 4030018980 S.CER C1608 JB 1H 104K-T
C1531 4030016790 S.CER C1005 JB 1E 103K-T
C1532 4030018980 S.CER C1608 JB 1H 104K-T
C1533 4030018980 S.CER C1608 JB 1H 104K-T
C1534 4030019490 S.CER C2012 JB 1A 106K-T
C1535 4030017790 S.CER C1005 JB 1H 682K-T
C1536 4030018980 S.CER C1608 JB 1H 104K-T
C1537 4030018980 S.CER C1608 JB 1H 104K-T
C1538 4030016790 S.CER C1005 JB 1E 103K-T
C1539 4030018980 S.CER C1608 JB 1H 104K-T
C1540 4030017490 S.CER C1608 JB 1A 105K-T
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T 90.5/106.7
T 101.3/97.5
T 85.6/110.0
T 86.8/110.0
T 85.6/105.2
T 105.4/89.4
T 83.9/110.0
T 140.7/98.0
T 140.7/103.2
T 83.0/105.2
T 102.4/89.7
T 102.7/93.7
T 82.5/110.0
T 141.2/93.4
T 100.4/90.8
T 126.5/106.7
T 100.2/92.0
T 129.6/112.3
T 131.3/90.7
T
T 135.6/94.7
T 136.4/92.1
T
T 130.5/105.7
T
T 142.5/83.8
T 131.3/87.8
T 129.0/84.4
T
T 129.6/105.7
T 146.2/79.3
T 133.2/105.7
T
T 133.4/107.6
T 132.6/109.4
T
T 113.9/20.0
T 121.1/16.7
T 141.5/73.5
T 143.0/68.1
T
T 138.5/60.8
T 130.8/69.2
T 138.2/59.2
T 117.1/18.0
T 143.0/64.0
T 126.6/68.3
T 112.0/14.5
T 135.0/58.0
T 132.7/53.7
T 116.8/11.5
T 128.6/19.7
T 116.8/10.1
T 127.4/56.0
T 138.3/55.0
T 144.1/50.7
T 143.9/52.3
T 119.8/13.9
B 125.4/52.9
T 136.0/52.2
B 125.4/50.9
T
B 127.0/47.2
T 126.9/41.0
T 143.3/48.1
B 127.0/45.0
T
T
T 127.1/31.5
B 124.7/44.3
T 143.3/45.1
T 130.8/31.4
T 134.3/12.2
T 127.8/45.3
T 128.9/12.6
T 135.5/41.0
T 131.5/15.7
T 124.9/29.0
T 115.9/43.4
T 137.8/32.3
T 115.3/41.5
T 135.4/33.7
T 144.2/33.1
T 130.6/28.7
T 128.5/25.4
T 134.3/41.0
T 122.0/50.1
T 143.8/23.3
T 123.2/50.1
T 134.0/28.7
T 115.4/46.9
T 111.9/46.6
T 146.7/23.3
T 141.1/20.7
T 127.3/12.3
T 110.2/50.9
T 137.7/18.2
T 109.0/36.4
T 109.3/38.0
T 108.2/50.9
T 137.9/22.7
B 121.1/37.5
T 109.2/50.9
T 116.5/38.8
T 105.6/49.4
[MAIN UNIT]
H/V REF PARTS
NO. NO.
C1541 4030019460 S.CER C1608 JB 0J 106M-T
C1543 4030018980 S.CER C1608 JB 1H 104K-T
C1545 4030018980 S.CER C1608 JB 1H 104K-T
C1546 4030017490 S.CER C1608 JB 1A 105K-T
C1547 4030006880 S.CER C1608 JB 1H 472K-T
C1548 4030018980 S.CER C1608 JB 1H 104K-T
C1550 4030006880 S.CER C1608 JB 1H 472K-T
C1551 4030016790 S.CER C1005 JB 1E 103K-T
C1553 4030006880 S.CER C1608 JB 1H 472K-T
C1555 4030018980 S.CER C1608 JB 1H 104K-T
C1556 4030006900 S.CER C1608 JB 1H 103K-T
C1557 4030006900 S.CER C1608 JB 1H 103K-T
C1558 4030006900 S.CER C1608 JB 1H 103K-T
C1601 4030017760 S.CER C1005 JB 1H 222K-T
C1602 4030017640 S.CER C1005 CH 1H 150J-T
C1603 4030017590 S.CER C1005 CH 1H 070C-T
C1604 4030017790 S.CER C1005 JB 1H 682K-T
C1605 4030017570 S.CER C1005 CH 1H 040B-T
C1606 4030017510 S.CER C1005 CH 1H 680J-T
95.4/93.9 C1607 4030017360 S.CER C1005 CH 1H 030B-T
C1608 4030017790 S.CER C1005 JB 1H 682K-T
C1609 4030017670 S.CER C1005 CH 1H 390J-T
96.2/92.0 C1610 4030017780 S.CER C1005 JB 1H 472K-T
C1611 4030019990 S.CER C1005 JB 1C 104K-T
94.5/93.9 C1612 4030017660 S.CER C1005 CH 1H 330J-T
C1613 4030017460 S.CER C1005 JB 1H 102K-T
C1614 4030017460 S.CER C1005 JB 1H 102K-T
C1615 4030017460 S.CER C1005 JB 1H 102K-T
81.9/93.5 C1616 4030017780 S.CER C1005 JB 1H 472K-T
C1617 4030017780 S.CER C1005 JB 1H 472K-T
C1618 4030019990 S.CER C1005 JB 1C 104K-T
C1619 4030017780 S.CER C1005 JB 1H 472K-T
90.1/90.7 C1620 4030017580 S.CER C1005 CH 1H 060C-T
C1621 4030019490 S.CER C2012 JB 1A 106K-T
C1622 4030017780 S.CER C1005 JB 1H 472K-T
91.0/89.0 C1623 4030017700 S.CER C1005 CH 1H 151J-T
C1624 4030019990 S.CER C1005 JB 1C 104K-T
C1625 4030017570 S.CER C1005 CH 1H 040B-T
C1626 4030017780 S.CER C1005 JB 1H 472K-T
C1628 4030019490 S.CER C2012 JB 1A 106K-T
74.9/93.8 C1629 4030017680 S.CER C1005 CH 1H 820J-T
C1631 4030017380 S.CER C1005 CH 1H 050B-T
C1632 4030017460 S.CER C1005 JB 1H 102K-T
C1633 4030017780 S.CER C1005 JB 1H 472K-T
C1634 4030017670 S.CER C1005 CH 1H 390J-T
C1636 4030017590 S.CER C1005 CH 1H 070C-T
C1637 4030017430 S.CER C1005 CH 1H 101J-T
C1638 4030017400 S.CER C1005 CH 1H 220J-T
C1639 4030017780 S.CER C1005 JB 1H 472K-T
C1640 4030017360 S.CER C1005 CH 1H 030B-T
C1641 4030017660 S.CER C1005 CH 1H 330J-T
C1642 4030017680 S.CER C1005 CH 1H 820J-T
C1643 4030017340 S.CER C1005 CH 1H 010B-T
C1644 4030017580 S.CER C1005 CH 1H 060C-T
C1645 4030017650 S.CER C1005 CH 1H 270J-T
C1646 4030017670 S.CER C1005 CH 1H 390J-T
C1647 4030017700 S.CER C1005 CH 1H 151J-T
C1648 4030019990 S.CER C1005 JB 1C 104K-T
C1649 4030017530 S.CER C1005 CH 1H 0R5B-T
C1650 4030017630 S.CER C1005 CH 1H 120J-T
C1651 4030017460 S.CER C1005 JB 1H 102K-T
127.5/8.8 C1652 4030017390 S.CER C1005 CH 1H 180J-T
C1653 4030017700 S.CER C1005 CH 1H 151J-T
C1654 4030017580 S.CER C1005 CH 1H 060C-T
C1655 4030017390 S.CER C1005 CH 1H 180J-T
C1656 4030017780 S.CER C1005 JB 1H 472K-T
134.3/6.0 C1657 4030017460 S.CER C1005 JB 1H 102K-T
134.3/8.5 C1658 4030011540 S.CER C1608 CH 1H 750J-T
C1659 4030017420 S.CER C1005 CH 1H 470J-T
C1660 4030017780 S.CER C1005 JB 1H 472K-T
C1661 4030017720 S.CER C1005 JB 1H 331K-T
C1662 4030017660 S.CER C1005 CH 1H 330J-T
C1663 4030017720 S.CER C1005 JB 1H 331K-T
C1664 4030017660 S.CER C1005 CH 1H 330J-T
C1665 4030017460 S.CER C1005 JB 1H 102K-T
C1666 4030017640 S.CER C1005 CH 1H 150J-T
C1667 4030017600 S.CER C1005 CH 1H 080C-T
C1668 4030017600 S.CER C1005 CH 1H 080C-T
C1669 4030017460 S.CER C1005 JB 1H 102K-T
C1670 4030017430 S.CER C1005 CH 1H 101J-T
C1671 4030017510 S.CER C1005 CH 1H 680J-T
C1702 4030017400 S.CER C1005 CH 1H 220J-T
C1703 4030017660 S.CER C1005 CH 1H 330J-T
C1704 4030019990 S.CER C1005 JB 1C 104K-T
C1705 4030019990 S.CER C1005 JB 1C 104K-T
C1706 4030019990 S.CER C1005 JB 1C 104K-T
C1707 4030019990 S.CER C1005 JB 1C 104K-T
C1708 4030019990 S.CER C1005 JB 1C 104K-T
C1709 4030019990 S.CER C1005 JB 1C 104K-T
C1710 4030019460 S.CER C1608 JB 0J 106M-T
C1711 4030017650 S.CER C1005 CH 1H 270J-T
C1712 4030019990 S.CER C1005 JB 1C 104K-T
C1713 4030017420 S.CER C1005 CH 1H 470J-T
C1714 4030017670 S.CER C1005 CH 1H 390J-T
C1715 4030019460 S.CER C1608 JB 0J 106M-T
C1716 4030019990 S.CER C1005 JB 1C 104K-T
C1717 4030019460 S.CER C1608 JB 0J 106M-T
C1718 4030017430 S.CER C1005 CH 1H 101J-T
C1719 4030017780 S.CER C1005 JB 1H 472K-T
C1720 4030017680 S.CER C1005 CH 1H 820J-T
C1721 4030019990 S.CER C1005 JB 1C 104K-T
C1722 4030017640 S.CER C1005 CH 1H 150J-T
C1723 4030017650 S.CER C1005 CH 1H 270J-T
C1724 4030017780 S.CER C1005 JB 1H 472K-T
C1725 4030017780 S.CER C1005 JB 1H 472K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-6
DESCRIPTION M.
LOCATION
T 143.7/17.6
T 110.6/44.2
T 137.9/14.7
T 105.9/38.8
T 108.9/46.1
T 143.7/14.7
T 105.9/35.9
T 100.3/51.3
T 98.7/37.0
T 102.5/49.2
B 91.8/47.8
B 80.1/47.8
B 83.4/47.8
T 95.1/48.6
T 105.8/60.3
T 106.7/59.0
T 93.8/49.8
T 92.5/50.2
T 106.7/57.4
T 103.7/59.9
T 91.3/49.8
T 103.7/56.3
T 78.6/47.2
T 89.8/52.6
T 57.4/55.5
T 54.1/59.1
T 101.2/59.5
T 97.2/57.3
T 61.9/59.4
T 83.0/51.7
T 83.4/49.6
T 75.3/48.5
T 64.8/51.5
T 81.9/49.0
T 72.5/44.0
T 65.7/51.5
T 80.2/47.2
T 64.8/48.9
T 55.9/59.8
T 79.2/51.1
T 65.7/48.9
T 64.8/46.6
T 94.3/58.4
T 69.4/67.8
T 65.7/46.6
T 65.2/45.0
T 97.5/61.2
T 69.0/43.9
T 60.3/64.4
T 67.7/43.4
T 69.0/43.0
T 94.0/57.2
T 68.2/41.9
T 93.7/59.6
T 68.6/66.4
T 69.5/41.7
T 90.9/60.5
T 68.6/69.2
T 66.3/38.1
T 90.4/58.4
T 61.7/67.0
T 66.0/35.9
T 90.1/56.7
T 66.0/35.0
T 88.1/57.5
T 59.4/68.8
T 66.0/36.8
T 87.9/56.4
T 87.9/61.7
T 64.7/67.8
T 87.0/61.7
T 85.7/62.2
T 83.4/59.8
T 83.0/62.2
T 62.7/40.9
T 65.2/56.2
T 59.0/39.7
T 58.6/41.0
T 56.1/55.0
T 60.8/70.0
T 72.5/42.1
T 55.5/41.8
T 55.5/40.1
T 54.1/38.3
T 54.1/39.3
T 54.1/40.2
T 54.1/41.8
T 61.2/47.6
T 54.2/49.8
T 42.7/50.1
T 43.5/61.1
T 43.0/47.7
T 46.7/61.1
T 49.3/48.7
T 49.4/34.0
T 49.1/35.0
T 42.7/48.8
T 46.7/63.9
T 51.4/65.1
T 43.5/62.6
T 43.9/44.8
T 44.0/64.0
T 43.5/65.4
T 42.0/41.3
T 64.4/35.0
S.=Surface mount
H/V
