Icom IC-F8100 Service Manual page 48

SECTION 7.
[CHASSIS PARTS]
REF ORDER
NO. NO.
W101** 8920000170 CAB-1017
W102** 8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
8920000550 CAB-1058
8920000550 CAB-1058
8920000580 CAB-1065
8920000550 CAB-1058
W103** 8970024762 1.5DCOAXIAL130MM-2 C31/C31
W107** 8900019690 OPC-2117 MJ0.4JC1.5/58AU
W108** 8900016110 OPC-1680 (P0.5N30L100)
W109** 8900016110 OPC-1680 (P0.5N30L100)
W110** 8900014871 OPC-1332A-1 (P0.5N40L100) TJM
W111** 8900019630 OPC-2067
W113** 8900020281 OPC-2083B <PHL>
W114** 8900019700 OPC-2128
W115** 8900018760 OPC-1969 (P0.5N20L60)
W116** 8900017660 OPC-1877 (P0.5N20L100)
W117** 8900020020 OPC-2139
W118** 8900020200 OPC-2146
W119 8920000490 CAB-1056
MP1 8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
8820000872 1705 CAP SCREW-2
MP2 8930070860 O-RING (BM) (TOT)
MP4 8820000530 FLANGE BOLT M4 X 8 NI
MP5 8810008661 PHBT M3 X 8 NI-ZC3
MP6 8810004301 PH M3 X10 ZK3
MP7 8810005771 BIND M3 X 8 ZK3BLACK
MP9 8930048550 2177 CLIP
MP10 8810003171 SET SCREWA M3 X 8 ZC3
MP11 8810007231 SET SCREWH M3 X 8 ZC3
MP16 8010021983 3296 CHASSIS-3
MP17 8110009990 3296 U-COVER
MP18 8110010000 3296 L-COVER
MP22 8930082010 3296 U-SEAL (TOT)
MP23 8930082020 3296 L-SEAL (TOT)
MP24 8930082030 3296 BUSH PLATE
MP25 8930082040 3296 A-BUSH PLATE
MP37 8810003161 SET SCREWA M3 X 6 ZC3
MP42 8930069580 THERMAL SHEET (BA) TC-600HS-1.4 (14.5
MP43 8930068820 THERMAL SHEET (AX)TC-600HS-1.4 (9.7)
MP44 8930053472 THERMAL SHEET (R)-2 TC200HS (10X10)
MP45 8950000180 CABLE TIE-80 (DENNISON DS-80)
MP46 6950000040 M-TYPE CAP (BLACK)
MP48 8930083200 MS-F SD460X610-T0 (50X50)
MP51 8930056211 SHIELD SPONGE (G)-1
MP52 8930056211 SHIELD SPONGE (G)-1
MP53 8930069680 FERRITE SHEET (P)
MP55 8930084360 HEXAGON SPACER (AH)
MP56** 8930007500 THERMAL SHEET J
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
[EXP-01]
[AUS-01]
[USA-01]
[UN-01]
[EXP-02]
[AUS-02]
[USA-02]
[UN-02]
[EXP-03]
[AUS-03]
[USA-03]
[UN-03]
[EXP-01]
[AUS-01]
[USA-01]
[UN-01]
[EXP-02]
[AUS-02]
[USA-02]
[UN-02]
[EXP-03]
[AUS-03]
[USA-03]
[UN-03]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[MAIN UNIT]
REF ORDER
QTY.
NO. NO.
J1001* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
1
1 J1002* 6510027580 16FLT-SM2-TB (LF) (SN) (M)
J1003* 6510027950 BM13B-SRSS-TBT (LF) (SN)
1
J1004* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1
J1005* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1
J1101* 6510018450 TMP-S01X-B1 0
1
J1102* 6510018450 TMP-S01X-B1 0
1
J1801* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
1
J1802* 6510028400 HU-1632-T
1
1
BT1001* 3020000400 CR1632/BK
1
1
1 EP1402* 6910002161 CASE-BM7H-LF
EP1404* 6910002161 CASE-BM7H-LF
1
EP1802* 6910002161 CASE-BM7H-LF
1
EP1803* 6910002161 CASE-BM7H-LF
1
1
MP1001* 8930065741 2590 D-EARTH SPRING-1
1
MP1003* 8510020070 3296 C-SHIELD CASE Y1218
1
MP1004* 8510020080 3296 D-SHIELD CASE Y1219
1
MP1005* 8510020190 3296 A-SHIELD PLATE Y1231
1
MP1006* 8510020140 3296 A-MAIN CASE Y1229
1
MP1007* 8510020150 3296 SHIELD PLATE Y1230
1
MP1009* 8510020130 3296 MAIN CASE Y1228
1
MP1010 8930065741 2590 D-EARTH SPRING-1
1
MP1012* 8930058840 SHIELD SPONGE (T)
1
MP1015* 8930058840 SHIELD SPONGE (T)
4 MP1016* 8930058840 SHIELD SPONGE (T)
MP1017* 8930065741 2590 D-EARTH SPRING-1
4
4
4
8
[PA UNIT]
8
8
REF ORDER
8
NO. NO.
4
4
J4001* 6510018450 TMP-S01X-B1
4
J4002* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
4
J4003* 6510015541 B4B-ZR-SM4-TF (LF) (SN)
1
J4004* 6510021531 IMSA-9230B-1-04Z024-PT1
1
J4005* 6510021531 IMSA-9230B-1-04Z024-PT1
30
J4006* 6510021391 IMSA-9230B-1-03Z024-PT1
6
J4007* 6510021391 IMSA-9230B-1-03Z024-PT1
8
J4008* 6510028210 SJ050010 (TMP-J01X-V6)
1
J4009* 6510027580 16FLT-SM2-TB (LF) (SN) (M)
5
J4010* 6510018961 B2B-PH-SM4-TB (LF) (SN)
2
J5001* 6510028210 SJ050010 (TMP-J01X-V6)
1
J5002* 6510018450 TMP-S01X-B1
1
J5005* 6510018450 TMP-S01X-B1
1
1
F4001* 5220000400 FHA010-01F
1
F4002* 5210000940 1205
1
1
S4001* 2260003250 DECASMDC050F/60-2 <UDX>
2
1
EP4004* 6910020710 OT-047 M3
4
EP4005* 6910020710 OT-047 M3
1
4
MP4001* 8510020760 3500 PA CASE
1
MP4002* 8930076670 THERMAL SHEET (BM)TC700HS1.4 (15X22)
2
MP4004 8930065741 2590 D-EARTH SPRING-1
1
MP4006 8930077680 3015 PA EARTH SPRING
1
MP4007* 8930065741 2590 D-EARTH SPRING-1
1
MP4008* 8510021040 3500 SHIELD PLATE
4
8510021040 3500 SHIELD PLATE
1
8510021040 3500 SHIELD PLATE
MP4009* 8930086691 2427 EARTH SPRING (A)-1
8930086691 2427 EARTH SPRING (A)-1
8930086691 2427 EARTH SPRING (A)-1
MP4010 8930079760 SHIELD SPONGE (CO)
MP4011 8930079760 SHIELD SPONGE (CO)
MP4012* 8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
MP4013* 8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
8930059330 SHIELD SPONGE (W)
MP5004* 8930065741 2590 D-EARTH SPRING-1
MP5005* 8930065741 2590 D-EARTH SPRING-1
MP5006* 8930065741 2590 D-EARTH SPRING-1
MP5007* 8930065741 2590 D-EARTH SPRING-1
