Indoor Cabinet
Outdoor
Cabinet

Cabinet Environment Parameters

ZXMSG 5200 cabinets are categorized as follows:
19D06H20 and ONU100 Indoor Cabinet
OUT30 and OUT50 Outdoor Cabinet
Table 16 lists environment parameters for indoor cabinet.
T 1 6 – E
A B L E N V I R O N M E N T
Name
Grounding
Resistance
Temperature
Control Method
Operating
Temperature
Relative Humidity
Atmospheric
Pressure
Operating Voltage
Air Conditioner
Air Pollution
Cabinet Fan
Rainproof and
Dust-Proof
Measures
Environment parameters of OUT30 and OUT50 cabinet are same.
Table 17 lists environment parameters for OUT30 and OUT50
cabinet.
T 1 7 – E
A B L E N V I R O N M E N T
Name
Operating Voltage
Operating Temperature
Electromagnetic
Interference
Confidential and Proprietary Information of ZTE CORPORATION
P
A R A M E T E R S
Description
≤ 10 ohm
Industrial air conditioning equipment
-35ºC ~ 40ºC
10% ~ 90%
5
1.08 * 10 Pa to 5.1 * 10
AC: 220 ± 10% VAC 50 Hz
240 ± 10% VAC 60 Hz
DC: –57 V DC ~ –40 V DC
Running Normally
Equipment must not expose to corrosive air,
such as hydrogen sulfide, sulfur dioxide, oxide
containing ammonia, or smoke such as any oil
solvent, smoke, and dust.
Running Normally
IEC IP 5.5 and adapts a special process for
major components to increase their corrosion-
proof capability
P O U T 3 0
A R A M E T E R S O F
Description
220 ± 10% V AC
-35ºC ~ 45ºC
Field intensity <= 140 dB V/m, the
frequency range is 0.01 MHz ~
1,10,000 MHz.
Chapter 2 System Description
4
Pa
O U T 5 0
A N D
23
