Ethernet Cards
Analog Line
Cards
Digital Line
Card
Table 8 lists Ethernet cards and their description.
T 8 – E C
A B L E T H E R N E T
Card Full Name
ETI Ethernet
Transform Card
ETC Ethernet
Transform Card
GETC Giga Ethernet
Transform Card
EPOL EPON Interface
Card long
distance
Table 9 lists analog line cards and their description.
T 9 – A L
A B L E N A L O G I N E
Card Full Name
ALC Analog Line
Card
RALC Polarity
Reversed
Analog Line
Card
FLC Far-end Line
Card
Table 10 lists digital line cards and their description.
T 1 0 – D L
A B L E I G I T A L
Cards Full Name
DLC Digital
Subscriber
Line Card
Confidential and Proprietary Information of ZTE CORPORATION
A R D S
Function
Ethernet layer 2
switching
function
Ethernet layer 2
switching
function
Ethernet layer 2
switching
function
OLT side related
functions
C
A R D S
Function
POTS access
POTS access and
reversed polarity
POTS access, reversed
polarity, 12 KC/16 KC
metering pulse and long
distance functions
C
I N E A R D S
Function
Basic rate interface for
ISDN. Transceiving of
2B+D data and format
conversion
Chapter 2 System Description
Port & Description
Six 100 Mbps Ethernet ports
Two FE ports
(Valid when control card is
ICS/EICS/GISS)
Two GE ports
(Valid when control card
board is GIS)
One SC optical port
connecting to 32 ONU of
EPON (via ODN)
Port & Description
32 analog
subscriber ports
32 analog
subscriber ports
16 analog
subscriber ports
Port &
Description
2B+D channel and
U interface function
of the ISDN
physical layer
