Universal
Protocol
Subsystem
Broadband
Protocol
Subsystem
Narrowband Protocol
Subsystem
Introduction
Functions
The universal protocol subsystem implements TCP protocol, UDP
protocol, IP protocol, ICMP protocol, ARP protocol, RARP protocol,
TFTP, FTP, HTTP, SNMP, and Telnet.
The broadband protocol subsystem modules are as follows:
MSTP module
STP
RSTP
MSTP
xDSL
ADSL
ADSL2+
VDSL
SHDSL
Multicast
IGMP snooping
IGMP proxy
IGMP router
QOS
VLAN
802.1Q
SVLAN
ETH port manager
Port configuration
Port trunking
Ethernet switch function configuration
Narrowband protocol subsystem includes V5 and H.248 for
PSTN/ISDN. It receives/transmits, processes calls and control
messages between users and ZXMSG 5200, and those between
ZXMSG 5200 and upper level Local Exchange (LE).
Service (call) Subsystem
Service subsystem operates according to protocol subsystem
commands.
The system functions are as follows:
Uniform service interfaces to upper layer
Shields hardware differences
Breaks down protocol commands to send to lower layer
Confidential and Proprietary Information of ZTE CORPORATION
Chapter 2 System Description
9
