over an IP network. They are connected to the uplink via the
ZXMSG 5200 FE/GE interfaces.
Features SHDSL features are as follows:

Ethernet Service

Introduction Ethernet service feature high bandwidth and less delay. Ethernet
has survived as the major LAN technology (it is currently used
for approximately 85 percent of the world's LAN-connected PCs
and workstations).
Functions Ethernet is used for UTP-5 medium-based 100BaseTx Ethernet
equipment access.
Standards Ethernet refers to a Local Area Network (LAN) family. IEEE
802.3 is Ethernet compliant standard that defines CSMA/CD
protocol. Ethernet twisted-pair cable defines four data rates for
operation as listed below:
Features Ethernet features are as follows:

VLAN Service

Introduction Virtual Local Area Network (VLAN) creates virtual workgroups by
dividing LAN logically, not physically, into different network
segments. VLAN is a broadcast domain. LAN and routers limit
broadcasts to the domain of origin.
Functions Virtual Local Area Network (VLAN) is established on the
switching technology. VLAN sends data 'intentionally' through
the switch and divides logical subnets flexibly while the
SHDSL supports symmetrical data across a single pair of
copper wire at data rates from 192 kbps to 2.3 Mbps or 384
kbps to 4.6 Mbps.
Maximum transmission distance is 3 km to 6 km.
ITU recommends G.991.2 and ANSI T1E1.4/2001-174 as
SHDSL standards.
10 Mbps Ethernet
100 Mbps Fast Ethernet
1000 Mbps Gigabit Ethernet
10,000 Mbps Gigabit Ethernet
Transmission distance less than 100 m
Easy to implement and manage
Low cost for network implementation
More flexible for
technology.
Confidential and Proprietary Information of ZTE CORPORATION
Chapter 3 Service Functions
network installation than the other
39
