Warnings and Alarms
16-90 Alarm
Bit Hex Dec Word
0 1 1 Brake check
1 2 2 Pwr.card temp
2 4 4 Earth Fault
3 8 8 Ctrl.card temp
4 10 16 Ctrl.word TO
5 20 32 Over Current
6 40 64 Torque limit
7 80 128 Motor th over
8 100 256 Motor ETR over
9 200 512 Inverter overld.
10 400 1024 DC under volt
11 800 2048 DC over volt
12 1000 4096 Short Circuit
13 2000 8192 Inrush fault
14 4000 16384 Mains ph. loss
15 8000 32768 "AMA Not OK"
16 10000 65536 Live zero error
17 20000 131072 Internal fault
18 40000 262144 Brake overload
19 80000 524288 U phase loss
20 100000 1048576 V phase loss
21 200000 2097152 W phase loss
22 400000 4194304 Fieldbus fault
23 800000 8388608 24V supply low
1677721
24 1000000 6 Mains failure
3355443
25 2000000 2 1.8V supply low
6710886
26 4000000 4 Brake resistor
1342177
27 8000000 28 Brake IGBT
1000000 2684354
28 0 56 Option change
®
VLT AQUA Drive
Operating Instructions
16-91 Alarm 16-92 Warning
Word 2 Word
ServiceTrip,
Read/Write Brake check
ServiceTrip,
(reserved) Pwr.card temp
ServiceTrip,
Typecode/
Sparepart Earth Fault
ServiceTrip,
(reserved) Ctrl.card temp
ServiceTrip,
(reserved) Ctrl.word TO
No Flow Over Current
Dry Pump Torque limit
End of Curve Motor th over
Broken Belt Motor ETR over
Discharge High Inverter overld.
Start Failed DC under volt
Speed Limit DC over volt
External
Interlock DC voltage low
Illegal Option
Combi. DC voltage high
No Safety
Option Mains ph. loss
No motor
Live zero error
KTY error 10V low
Fans error Brake overload
ECB error Brake resistor
Brake IGBT
Speed limit
Fieldbus fault
24V supply low
Mains failure
Current limit
Low temp
Voltage limit
Encoder loss
®
MG.20.M8.02 - VLT is a registered Danfoss trademark
16-93 Warning 16-94 Ext.
Word 2 Status Word
Start Delayed Ramping
Stop Delayed AMA Running
Clock Failure Start CW/CCW
Fire Mode was
Active Slow down
Catch up
No Flow Feedback high
Dry Pump Feedback low
Output current
End of Curve high
Output current
Broken Belt low
Discharge High Output freq high Quick Stop
Multi-motor
underload Output freq low
Multi-motor
Overload Brake check OK
Compressor
Interlock Braking max
Mechanical Brake
Sliding Braking
Safe Option Out of speed
Warning range
Auto DC Braking OVC active
AC brake
Password
KTY warn Timelock
Password
Fans warn Protection
ECB warn Reference high
Reference low
LocalRef /
RemoteRef
Protection mode
notification
Unused
Unused
Unused
Unused
Unused
Unused
16-95 Ext.
Status Word 2
Off
Hand/Auto
Profibus OFF1
active
Profibus OFF2
active
Profibus OFF3
active
Relay 123 active
Start Prevented
Control Ready
Drive Ready
DC Brake
8 8
Stop
Stand by
Freeze Output
Request
Freeze Output
Jog Request
Jog
Start Request
Start
Start Applied
Start delay
Sleep
Sleep Boost
Running
Drive Bypass
Fire Mode
External Interlock
Firemode Limit
Exceed
FlyStart active
