ML20700 PWI/PIP Series Mortise Lock
14. Install Inside Escutcheon
1. Install cover by hooking top edge on inside mounting plate.
2. Carefully press bottom of cover toward door without pinching wires.
3. Secure the cover with the security allen wrench.
Copyright © 2016 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
6) PIP (PoE) Wiring & Installation (Continued)
End of PIP (PoE) Installation Instructions
Proceed to Section 8 - Operational Check
Important Note:
If you are installing PWI (Wireless) go to next page
Fig. 14
