ML20700 PWI/PIP Series Mortise Lock
Copyright © 2016 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
6) PIP (PoE) Installation Wiring & Installation
Overview
Corbin Russwin ML20700 PIP (PoE) Typical Application
Network Switch (802.3af)
LMT: Lock Management Tool
A. PoE frame harness assembly
B. PoE data hinge from McKinney
C. PoE door harness* from McKinney
D. CL33700 PIP PoE Lock
E. DPS: Door Status Switch
(not required for ML207xx)
* Door width determines length
Network Cable
Surface Mount RJ45
A
B
16
D
C
E
