Assa Abloy TCPWI1 Installation Instructions Manual page 17

ML20700 PWI/PIP Series Mortise Lock
Supplied by CI
B-Splice
Crimp Connector
RJ45-M
Ceiling
24AWG
Stranded
Drain
Wire for
Earth
Ground in
15' Frame
Harness
Frame-Side
Harness
Assembly
(15' length)
Cable
drain wire
concealed
in shrink
tubing
Molex-F
Molex-M
A
Copyright © 2016 Corbin Russwin, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the
express written permission of Corbin Russwin, Inc. is prohibited.
6) PIP (PoE) Wiring & Installation
Certified Integrator (CI) supplies and terminates
the B-Splice connector and the
Male RJ45 connector from harness to
end user provided facility cable
To building or electrical ground
RJ45-F Jack Cable: CAT 5e or higher
24 AWG
Cable
: CAT 5e,
26 AWG stranded,
shielded, 100ohm
C
Molex-F Molex-M
B
Ring Terminal
Secured to Lock
Mounting Plate
Wiring to TIA/EIA 568-B Standard
Patch Cable
Patch Panel to
PoE Switch
D
PoE
Lock
RJ45-M
Ground
17
Supplied by End User
PoE Switch
PoE Switch is
Terminated to
Earth Ground
Patch Panel
Approved Software
Notes:
• Connectors go on only one
way. They cannot be placed
in an incorrect position.
• Do not force and do not
offset connectors
• Be sure they are completely
seated (flush)
• PoE power source cannot
be connected to a receptacle
controlled by a switch
