Technical data and dimensions

Materials: ................................... Steel plate, cast iron, galvanised sheet,
vermiculite
Surface treatment: ........................................................................... Senotherm
Max. log length: ........................................................................................... 26 cm
Weight Scan 83-1 / Scan 83-2: .................................................. approx. 117 kg
Weight Scan 83-3 / Scan 83-4: .................................................approx. 125 kg
natural stone/tile
Weight Scan 83-5/6,
Weight Scan 83-7 / Scan 83-8: ................................................ approx. 212 kg
Fresh air connection piece external diameter: .............................100 mm
Flue connection piece internal diameter: ...................................... 144 mm
Flue connection piece external diameter: ..................................... 148 mm
Approval type: ............................................................ Intermittent operation
Intermittent operation in this context means normal use of a wood-
burning stove. In other words, you should let the fire die down until
only the embers are left before refuelling.
The Scan 83 Series is produced in accordance with type approval for
the product, which also covers the product's Assembly and Instruction
Manual.
The Declaration of Performance (DoP) is available from http://scan.dk
Tested in accordance with EN 13240
Scan 83 Series
CO emissions at 13% O 2
CO emissions at 13% O2
Dust @ 13% O 2
No x @ 13% O 2
Efficiency
Nominal output
Chimney temperature EN 13240
Temperature in flue connection piece
Amount of smoke
Negative pressure EN 13240
Recommended negative pressure in flue con-
nection piece
Required combustion air supply
Fuel
Fuel consumption
Amount of fuel required to light
* based on 896 mg/Nm 3
TECHNICAL DATA
: ..................approx. 186/132 kg
Technical data
* 0.07
896
23
106
81
5
227
280
5
12
16
14
Wood
1.6
1.4
Unit
%
mg/Nm 3
mg/Nm 3
mg/Nm 3
%
kW
°C
°C
g/sec
Pa
Pa
Nm 3 /h
Wood
kg/h
kg
