DAQ-Sync signals

The DAQ-Sync hardware provides the capability of triggering or clocking up to four slave boards from a master
board to synchronize data input and/or output.
The PCI-DAS6034, PCI-DAS6035, and PCI-DAS6036 boards provide the capability of inter-board
synchronization between boards in the PCI-DAS6000 family. There are five trigger/strobes and a synchronizing
clock provided on a 14-pin header. The available signals are:
DS A/D START TRIGGER
DS A/D STOP TRIGGER
DS A/D CONVERT
DS D/A UPDATE (PCI-DAS6035 and PCI-DAS6036 only)
DS D/A START TRIGGER (PCI-DAS6035 and PCI-DAS6036 only)
SYNC CLK
Auxiliary I/O signals
Signal Name
A/D CONVERT
A/D EXT. TIMEBASE IN
A/D START TRIGGER
A/D STOP TRIGGER
A/D PACER GATE
D/A START TRIGGER
D/A UPDATE
D/A EXT. TIMEBASE IN
STARTSCAN
SSH
A/D STOP
A/D CONVERT
SCANCLK
CTR1 CLK
D/A UPDATE
CTR2 CLK
A/D START TRIGGER
A/D STOP TRIGGER
D/A START TRIGGER
AUXIN0
AUXIN1
AUXIN2
AUXIN3
AUXIN4
AUXIN5
AUXOUT0
AUXOUT1
AUXOUT2
DAQ-Sync signals
18
Function
External ADC convert strobe (default)
External ADC pacer time base
ADC Start Trigger (default)
ADC Stop Trigger (default)
External ADC gate (default)
DAC trigger/gate (default)
(PCI-DAS6035 and PCI-DAS6036 only)
DAC update strobe (default)
(PCI-DAS6035 and PCI-DAS6036 only)
External DAC pacer time base
(PCI-DAS6035 and PCI-DAS6036 only)
A pulse indicating the start of conversion.
An active signal that negates at the start of the last
conversion in a scan.
Indicates end of an acquisition sequence
ADC convert pulse (default)
Delayed version of ADC convert (default)
CTR1 clock source
D/A update pulse (default) (PCI-DAS6035 and
PCI-DAS6036 only)
CTR2 clock source
ADC Start Trigger Out
ADC Stop Trigger Out
DAC Start Trigger Out
A/D CONVERT
A/D START TRIGGER
A/D STOP TRIGGER
D/A UPDATE (PCI-DAS6035 and PCI-DAS6036 only)
D/A START TRIGGER (PCI-DAS6035 and
PCI-DAS6036 only)
A/D PACER GATE
D/A UPDATE (PCI-DAS6035 and PCI-DAS6036 only)
A/D CONVERT
SCANCLK
