PCI-DAS6034, PCI-DAS6035, and PCI-DAS6036 User's Guide
Table 2. Absolute accuracy components specifications - all values are (±)
Range % of
Reading
±10 V 0.0239
±5 V 0.0262
±500 mV 0.0467
±50 mV 0.0685
1
Averaged measurements assume averaging of 100 single-channel readings.
Each PCI-DAS6034, PCI-DAS6035, and PCI-DAS6036 is tested at the factory to assure the board's overall
error does not exceed accuracy limits described in Table 1.
All ranges

System throughput

Condition
1. Single channel, single input range
2. Multiple channel, single input range
3. Single channel, multiple input ranges
For conditions 1-2 above, specified accuracy is maintained at rated throughput. Condition 3
Note 2:
applies a calibration coefficient which corresponds to the range value selected in
This coefficient remains unchanged throughout the scan. Increased settling times may occur
during gain-switching operations.

Settling time

Settling time is defined as the time required for a channel to settle to within a specified accuracy in response to
a full-scale (FS) step. Two channels are scanned at the specified rate. A –FS DC signal is presented to
channel 1; a +FS DC signal is presented to channel 0.
Condition
Same range to same range

Parametrics

Max working voltage
(signal + common-mode)
CMRR @ 60 Hz
Small signal bandwidth, all ranges
Input coupling
Input impedance
Input bias current
Input offset current
Offset Averaged Noise +
(µV) Quantization (µV)
531 180
274 85
54 12.3
21.2 6.54
Table 3. Differential non-linearity specifications
±0.5 LSB typ
Calibration Coefficients
Per specified range
Per specified range
Default to value for cbAInScan() range parameter
Range
±10 V
±5 V
±500 mV
±50 mV
±11 V
±10 V range:
±5 V range:
±500 mV range: 93 dB
±50 mV range: 93 dB
413 kHz
DC
100 GOhm in normal operation.
2 kOhm typ in powered off or overload condition.
±200 pA
±100 pA
Temp Drift
1
(%/DegC)
0.001
0.001
0.001
0.001
±1.0 LSB max
Accuracy
±0.0031%
(±2.0 LSB)
5 µS max
5 µS max
5 µS typ
*
85 dB
85 dB
31
Specifications
Absolute Accuracy
at FS (mV)
3.10
1.67
0.30
0.062
ADC Rate (max)
200 kS/s
200 kS/s
200 kS/s
.
cbAInScan()
±0.0062%
(±4.0 LSB)
*
*
*
5 µS typ
