4. On the pop-up message box, click Yes to restart the device to enable the CVBS output or HDMI2 as the main
output.
You can select the Menu Output Mode under Menu>Configuration>More Settings to Auto, or HDMI (1)/VGA
and then restart the device to switch the main output back to HDMI (1)/VGA output.

3.2.4 HDMI and VGA Non-Simultaneous Output

DS-7308HQHI-SH, DS-7316HQHI-SH, DS-8008HQHI-SH, DS-8016HQHI-SH, DS-8108HQHI-SH,
DS-8116HQHI-SH, DS-9008HQHI-SH, and DS-9016HQHI-SH support HDMI and VGA non-simultaneous
output.
Steps:
1. Enter the Configuration Menu
Menu > Configuration
2. Click More Settings to enter the more settings interface.
3. Do not check the checkbox of Enable HDMI/VGA Simultaneous Output and then click Apply to pop up
the Attention box and click Yes to reboot the device to have new settings taken effect.

3.2.5 Quick Setting Toolbar in Live View Mode

On the screen of each channel, there is a quick setting toolbar which shows when you point the mouse to the
bottom of the screen.
Icons Description
Enable/Disable
/ Manual Record
Digital Video Recorder User Manual
Figure 3. 3 More Settings Interface
Figure 3. 4 Quick Setting Toolbar
Table 3. 7 Description of Quick Setting Toolbar Icons
Icons Description
Instant Playback
56
Icons Description
Mute/Audio on
/
