DS-9000HQHI-SH

Model
Video compression
Analog and HDTVI video
input
Supported camera types
Video/Audio
IP video input
input
Audio compression
Audio input
CVBS output
HDMI/VGA output
Encoding resolution
Frame rate
Video/Audio
output
Video bit rate
Audio output
Audio bit rate
Dual stream
Stream type
Synchronous playback
Incoming bandwidth
Network
Remote connection
management
Network protocols
SATA
Hard disk
eSATA
Capacity
Two-way audio input
Network interface
External
interface
Serial interface
USB interface
Alarm in/out
Power supply
Consumption
(without HDD)
Working temperature
General
Working humidity
Dimensions (W × D × H)
Weight (without HDD)
Digital Video Recorder User Manual
DS-9004HQHI-SH
H.264+/H.264
4-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
720p/25Hz, 720p/30Hz, 720p/50Hz, 720p/60Hz, 1080p/25Hz, 1080p/30Hz, CVBS
6-ch (up to 10-ch)
Up to 5 MP resolution
G.711u
4-ch
RCA (2.0 Vp-p, 1 KΩ)
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280
× 720/60Hz, 1024 ×
768/60Hz
1080p/720p/VGA/WD1/4CIF/CIF
Main stream:
1080p/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;
CIF/QCIF/QVGA@25fps (P)/30fps (N)
32 Kbps to 10 Mbps
2-ch, RCA (Linear, 1 KΩ, for VGA and CVBS output respectively)
64 Kbps
Support
Video, Video & Audio
4-ch
110 Mbps
128
TCP/IP, PPPoE, DHCP, Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI,
UPnP™, HTTPS
8 SATA interfaces
Support
Up to 6 TB capacity for each disk
1-ch, RCA (2.0 Vp-p, 1 KΩ), using the audio input
2, RJ45 10M/100M/1000M self-adaptive Ethernet interface
RS-232, RS-485, Keyboard
3 × USB 2.0
16/4
100 to 240 VAC
≤ 35 W
-10 ºC to +55 ºC (14 ºF to 131 ºF)
10% to 90%
445 × 470 × 90 mm (17.5 × 18.5 × 3.5 inch)
≤ 8 kg (17.6 lb)
236
DS-9008HQHI-SH DS-9016HQHI-SH
8-ch 16-ch
10-ch (up to 18-ch) 18-ch (up to 32-ch)
8-ch 16-ch
HDMI: 1-ch, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz,
1280 × 720/60Hz, 1024 × 768/60Hz
8-ch 16-ch
160 Mbps 260 Mbps
≤ 45 W ≤ 65 W
