Selecting The Touch Panel - Brother PT-P950NW User Manual

Using the Touch Panel Display (Optional:PA-TDU-003) (PT-P950NW Only)
e
Select the [Switch Label] folder, and then click [Transfer]. If a confirmation message appears, click
[OK]. Transferring begins.
Note
• Up to 99 templates can be registered with this P-touch Label Printer.
• If a new template is transferred with the same key number as another template already registered on the
P-touch Label Printer, the new template will overwrite the old one.

Selecting the Touch Panel

Two touch panels, basic control panel (A) and one-touch panel (B) can be selected for the touch panel
display.
If the one-touch panel (B) will be used, the data to be assigned to the one-touch panel keys must be specified.
For more information on specifying the settings, see Selecting the Data Assigned to Keys on the One-Touch
Panel on page 214.
a
Press [ ] (settings key).
b
Press [b], select [Set Panel], and then press [OK].
c
Press [a] or [b], select [A] or [B], and then press [OK].
d
Follow the on-screen instructions to replace the touch panel. (For more information on replacing it, see
Replacing the Touch Panel on page 197.)
e
Make sure that the specified touch panel name shown on the screen matches the name of the touch
panel you are using, and then press [PRINT].
24
24
213
