- Page 1 D/N 1080P HD Fast Dome IR IP Camera IPS2102E Instr uction Manual...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION： TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... - Page 3 IPS2102E with High resolution of HD/Full HD offer significant enhancement and refinements to bring you the most innovative surveillance solutions. IPS2102E are the leading product in the industry offering the most advanced features such as 10X optical zoom lens, Digital Zoom, Auto Focus Control, Auto Iris Control, Day & Night Control, Infrared LED Control, Wide Dynamic Range, Digital Noise Reduction , High Light Compensation and Digital Image Stabilizer ...
- Page 4 FEATURES Auto Focus Lens Build-in 10X optical zoom lens with focal length 4.9 ~ 49mm Day & Night (IR cut removable) 1920x1080(1080P) Horizontal TV lines Automatic/Manual Iris Control High efficiency infrared LED 850nm, radiant distance - 16meters Private Mask ° 360 continuous rotation Up to 128 programmable preset positions Preset positions auto scanning...
-
Page 5: Warnings And Cautions
WARNINGS & CAUTIONS Please read the manual before attempting installation or operation 1. Please be aware to the warnings and cautions notice. 2. Don't use any chemical detergent to clean the machine surface, use a damp cotton cloth only. Regularly clean the dome cover to assure proper focus ability. 3. -
Page 6: Structural Element
STRUCTURAL ELEMENT DC12V Power Cable Video Signal Cable Signal Shield Wire Signal Shield Wire CAT5 Network Cable Camera Body Camera Case Bottom Chassis Power In DC Jack (DC12V In DC Jack) ± DC Input: DC12V 10% Video Out BNC Jack Video Signal Output: CVBS 1.0Vp-p 75 Ω... -
Page 7: Installation
INSTALLATION Attached Mounting Installation Structural Drawing Attached Mounting (Fixed Ceiling) Step 1 Fix The Metal Clips of ceiling 120° ψ30 Put fixed metal clips on Tighten the three tapping Loose the screw of bottom Base size and screw installation position of screws into the ceiling. - Page 8 Step 3 Connection AUDIO IN VIDEO OUT AUDIO OUT Connect Ethernet cable. Connect DC12V of power Connect Video signal Connect Audio in/out cable. (Suggest to use the cable. signal cable. ADAPTOR from the factory) Wall Mounting (Fixed Bracket) Step 1 Fix The Bracket & Metal Clips of Bracket Fixed bracket first, and Set all of control cable Tighten the three screws...
-
Page 9: Specification
SPECIFICATION 1 0 X D / N 1 0 8 0 P H D FA S T D O M E I R I P C A M E R A General Model IPS2102E Power Supply DC12V PoE+ (IEEE 802.3at) Power Consumption 15.5W... - Page 10 Android support System integration ONVIF & LILIN HTTP API CMX HD3.6 support Video display LILIN Universal ActiveX & LILIN Java Applet Embedded Linux 2.6.32 Two-way Audio G.711 SD Card Recording Support Micro SD/SDHC card for circular recording(card is not included) Design and specification are subject to change without notice.
- Page 11 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-IPS210CSE...
