  • Page 1 D/N CMOS HD IP CAMERA IPG012ES INSTRUCTION MANUAL...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3 CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
  • Page 4 CONGRATULATIONS Thank you for purchasing this D/N CMOS HD IP Camera. You now own one of the many fine CCTV products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition. With reasonable care, it will provide years of reliable performance.

  • Page 5: Warranty Information

    Also it provides higher bit rate of internet and diverse alarm functions such as external alarm or movement video detection e-mail or FTP. Moreover, IPG012ES can do remote surveillance with Java or iPhone cell phone. The software R&D engineer can use HTTP protocol(HTTPAPI) to develop related...

  • Page 6: Part Description

    PART DESCRIPTION 112mm 54mm IRIS POWER LEVEL CARD RESET N.O. +5V COM. GND AUDIO IN AUDIO OUT DC12V VIDEO OUT 56mm...
  • Page 7 1. LENS MOUNT CAP Prevent damages to the image sensor and to keep dust away. FOCAL LENGTH ADJUSTMENT RING AND LOCKING SCREW Use this ring to adjusts the back-focal distance or picture focus. Rotate this ring clockwise or counterclockwise for a CS-mount lens. Use the locking screw to lock the focal length.
  • Page 8 10. IRIS LEVEL ADJUSTMENT VOLUME Adjusts the signal level when DC control type auto iris lens is in use. 11. SD CARD SLOT This network camera is compliant with SD/SDHC card. 12. AUDIO INPUT RCA CONNECTOR Audio signal input. 13. AUDIO OUTPUT RCA CONNECTOR Audio signal output.
  • Page 9 IR CUT REMOVABLE EXTERNAL CONTROL SETUP Access into web page setup menu, under schedule menu, enable External Control option, the alarm input function will be turned off, DIN input is switched to day/night external control mode. External input mode: normally open(NO) or normally closed(NC) mode is selectable.

  • Page 10: Installation

    INSTALLATION SUITABLE LENSES The lens must be either a C or CS mount type. The protrusion behind the mounting surface must be within the following limits: C - mount lens CS - mount lens 9mm or less 4mm or less...
  • Page 11 CHANGING THE PLUG ON AN AUTO IRIS LENS CABLE The camera is supplied with a plug to fit the AUTO IRIS connector. To connect an auto iris lens, first replace the plug on the lens cable with the supplied plug. Solder the lens cable to the pins of the supplied plug (For cable pin assignment, refer to the instruction manual for the lens.).
  • Page 12 FITTING THE LENS Remove the lens mount cap. Screw in the C mount ring(not supplied), unit it is secured. When using a CS mount lens skip step2. Screw in the lens, unit it is secured. Insert the lens plug in the AUTO IRIS connector, when fitting a manual- iris lens, skip step4.
  • Page 13 FITTING THE CAMERA 1. The mounting base can be attached to either the top or bottom of the camera. 2. Tighten the screw to attach the mounting base. Please refer to the following drawing.

  • Page 14: Product Components

    IPD552EX2.2/4.2 N/P INSTRUCTION MANUAL INSTRUCTION MANUAL 1. CD Software Pack SYSTEM ARCHITECTURES For connecting IPG012ES to the network, please follow one of the system architectures: (1). Hardware Installation using a PoE Switch. LAN / Internet PoE Switch IPG012ES (2). Hardware Installation using a non-PoE Switch.

  • Page 15: Emergency Factory Default

    (3). Hardware Installation using DC12V Adaptor. LAN / Internet Non-PoE Switch IPG012ES DC12V Adaptor EMERGENCY FACTORY DEFAULT To restore the server to factory default settings, please: 1. Hold Reset Key for 10 seconds. 2. The network LED lights turn off after about 20 seconds, then lit.

  • Page 16: Specifications

    SPECIFICATIONS D/N CMOS HD IP CAMERA IPG012ES Model No. Pick Up Element 1/4" Progressive scan CMOS sensor Effective Pixels 1280(H) x 800(V) = 1,024,000(pixel) Chip Size 3.88mm(H) x 2.43mm(V) Scanning System Progressive Scan Infrared Cut Filter Auto / Schedule / Day(Color) / Night(Mono) / External Control Min.
  • Page 17 Android support Support System Integration ONVIF Free CMX support Video Display LILIN Universal ActiveX / Quick Time Embedded Linux 2.4.19 Two-way Audio G.711 / PCM Support SD/SDHC card for circular recording SD Card Recording (card is not included) Alarm Input / Output Digital 1 input (TTL, +3~5V) / 1 Output (N.O.)
  • Page 18 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-IPG012CSE...
