D/N 1080P HD Infrared IP Camera
IPR722ES / LR7022E
Instr uction Manual

Advertisement

Table of Contents
loading

Related Manuals for Lilin iMEGAPRO IPR722ES

Summary of Contents for Lilin iMEGAPRO IPR722ES

  • Page 1 D/N 1080P HD Infrared IP Camera IPR722ES / LR7022E Instr uction Manual...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION： TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3 CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
  • Page 4 CONGRATULATIONS Thank you for purchasing this D/N 1080P HD Infrared IP Camera. You now own one of the many fine network products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition. With reasonable care, it will provide years of reliable performance.
  • Page 5 Executive Summary IPR722ES & LR7022E series is an 2 megapixel day&night 1080P HD Infrared IP Camera, built-in H.264 AVC (Advanced Video Coding) video compression. H.264 AVC video compression engine supports high definition video quality, 1080P(1920x1080) resolution, bandwidth efficiency with PPPoE and DDNS. Also it provides higher bit rate of internet and diverse alarm functions such as movement video detection e-mail or FTP.

  • Page 6: Part Description & Dimension

    PART DESCRIPTION & DIMENSION 72.5 Unit: mm...

  • Page 7: Installation

    TOP COVER BOTTOM CHASSIS BRACKET PAN ADJUSTMENT SCREW TILT ADJUSTMENT SCREW WINDOW RJ-45 NETWORK CONNECTOR (Support PoE) DC POWER INPUT JACK (DC12V 10%) ± RESET KEY To restore the server to factory default setting. NETWORK INDICATOR LEDS Green (LINK): While cable of network is connecting the LED is light. Orange (ACT): When data is communicating, the LED is flashed.
  • Page 8 2. Loosen the pan and tilt adjustment screw on the bracket to turn the camera 　 body to the desired angle and then tighten the screws(FIG.3). FIG. 3 PRODUCTION COMPONENTS 1. D/N 1080P HD Infrared IP 2. Instruction Manual Camera 　...
  • Page 9 SYSTEM ARCHITECTURES For connecting IPR722ES & LR7022E series to the network, please follow one of the system architectures: (1). Use DC12V power adapter and network switch connected to a network. LAN / Internet Non-PoE Switch HD Infrared IP Camera DC12V Adaptor (2).

  • Page 10: Emergency Factory Default

    EMERGENCY FACTORY DEFAULT Use hardware to restore factory default settings, follow these steps: 1. Hold "RESET" key 10 seconds, then release. 2. After about 40 seconds, the network LED light is off, and then lit. 3. This camera has completed the factory default settings, and then reboot. 4.

  • Page 11: Specifications

    SPECIFICATIONS IPR722ES (1080P 30fps) D/N 1080P HD INFRARED IP CAMERA IPR722ES4.3 IPR722ES6 Model No. 4.3mm Focal Length F1.6 F1.8 Lens Iris Angle of View 70 (H), 51 ° ° (V), 89 (D) ° 49.3 (H), 35.9 ° ° (V), 64.5 (D) °...
  • Page 12 Mobile Phone and PDA iPad, iPhone and Android support System Integration ONVIF & LILIN HTTP API CMX HD3.6 support Video Display LILIN Universal ActiveX & LILIN Java Applet Embedded Linux 2.6.32 Design and specification are subject to change without notice.
  • Page 13 LR7022E (1080P 15fps) D/N 1080P HD INFRARED IP CAMERA LR7022E4 LR7022E6 Model No. Focal Length F1.6 F1.8 Lens Iris Angle of View 62.2 (H), 37.4 ° ° (V), 69.2 (D) ° 43.6 (H), 25.4 ° ° (V), 49.4 (D) ° Pick Up Element 1/2.5"...
  • Page 14 Mobile Phone and PDA iPad, iPhone and Android support System Integration ONVIF & LILIN HTTP API CMX HD3.6 support Video Display LILIN Universal ActiveX & LILIN Java Applet Embedded Linux 2.6.32 Design and specification are subject to change without notice. 66-IPR722ECSE-1...
  • Page 15 MERIT LILIN ENT. CO., LTD http://www.meritlilin.com 66-IPR722ECSE...
