3. Controls & Functions
FRONT : XVM-175W
[F1] (In Single Mode) button/lamp
●
- This Functions button is used to activate the
feature selected in "System- KEY FUNCTION
1 " menu.
[F1](In Multi Mode) button
●
- Used to select a display in Multi Mode.
[F2] button/lamp
●
- This Functions button is used to activate the
feature selected in "System- KEY FUNCTION
2 " menu.
[F3] button/lamp
●
- This Functions button is used to activate the
feature selected in "System- KEY FUNCTION
3 " menu.
[F4] button/lamp
●
- This Functions button is used to activate the
feature selected in "System- KEY FUNCTION
4 " menu.
[F5] button/lamp
●
- This Functions button is used to activate the
feature selected in "System- KEY FUNCTION
5" menu.
XVM-175W_245W-N_325W-EN_V2.4.indd 9
[MENU/EXIT] button
●
- Used to activate the OSD menu.
- When the OSD menu is activated, press this
button to exit from the menu.
[UP/DOWN/ENTER] Knob
●
- Used to move within the menu when OSD
menu is activated and is also used to
decrease or increase the value of the
selected feature.
- Press the knob to select the main menu and
sub menus.
- When OSD menu is inactivated, press
the knob to adjust the value of Volume,
Brightness, Contrast or Aperture.
[ENTER] button
●
- Used to confirm a chosen value (or mode).
It may also be used to control the VOLUME
value during OSD menu inactivation.
[TALLY] lamp
●
- LED indicating monitors current status.
[USB]
●
- The USB port for easy firmware updates.
[PHONE JACK]
●
- Used to Stereo Audio Output through Phone
Jack.
Multi Format LCD Monitor 9
